40W LED Wall Pack

40W LED Wall Pack

/
DETAIL

Product Description

KAIWIM LED wall pack is designed to replace metal halide/high pressure solid wall pack. It can replace 50W-400W metal halide wall pack with lighting efficacy up to 139lm/w, over 75% energy saving.
Constructed with high quality thermal heat sink, features excellent heat dissipation, LED TC<75°C(25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
The housing is designed to be mounted on junction boxes or direct wall mounts with feed through conduit access for easy installation.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, emergency back-up, etc.
LED Wall Pack series is IP65 rated, suitable for damp and wet locations, the fixture is ideal for outdoor walkways, entry ways, pathways, landscapes, public areas, security lighting, etc.


Specification Summary

 Power (W) 40W 40W 40W
Color Temperature (CCT) 4000K 4500K 5000K
Lumen Output (LM) 5,234 5,234 5,234
Efficacy (lm/W) 131 131 131
Input Voltage (V) 100-277V
Power Factor >90%
THD <20%
CRI 73
Optics UV Resistant High Quality PC Lens
Beam Angle (°) 70°x110°
Dimensions (in) 13.1''(L) x 9.5''(W) x 7.5'' (H)
LED Class UL Listed: LM80
Driver Class UL Listed: Class II
Controls Dimming, Sensors, Emergency battery back-up available
Environment Outdoor & Indoor Applications
Operating Temperature –25°C to +45°C
Certifications UL/cUL, LM79, LM80
L70 Lifetime (hours) 150,000 hours per L70 TM-21@ 25°C
Warranty 6-year limited system warranty standard


Features

• High system efficacy up to 139 LPW
• Class II UL listed driver
• Die-casting Aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Sealed to be dirt and bug proof
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 75%



Controls

• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Surge protector (over current device) optional

Installation

• Wall mount, can mount to recessed outlet boxes
or directly to surfaces

Housing & Finish

• Die-casting Aluminum heat sink
• UV resistant high quality Lens(Std.)
• Tempered and shatter-resistant glass optional
• Bronze finish standard, black and white optional
• RAL & custom colors available

Compliance

• DLC Standard
• ETL/cETL listed (14W, 22W)
• UL/cUL listed (40W, 60W, 80W, 100W)
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available

Optics

• 100°x 85° for Mini Wall Pack
• 70°x 110° for Forward Throw Wall Pack

Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C

Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming

Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.

Nichia LED

High Quality Nichia LED Chips

1.Top brand high quality Nichia chips (L90>50,000hrs).
2.Super high light efficacy.
3.EnGreen Inovaneered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.

UV resistant high quality PC lens

1. Patent unique design.
2. Meet DLC Premium 4.0 lighting requirment, NO need extra cover or shield.
3. Light-weight than traditional glass cover.
4.Shatterproof.
5. Btter waterproof performance.
6. UV resistant, NO NEED TO WORRY DISCOLOR.

 Wall Pack (2)
LED-Wall-Pack-Light

Various Options

1. Available with 0-10v Dimmable driver.
2. For Medium /Large WP: Photocell, Motion sensor &
Remote controller, dimming driver, Emergency battery back
up unit etc.
3. 100-277V and 347-480V available.
4. Our Patent unique design.
5. Better heat dissipation, no need addtional heat sink.
6. Conduit entrances on back, side and bottom.


Dimension

40W LED Wall Pack 80W LED Wall Pack


Applications

• Area Lighting
• Security Lighting
• Building Accent Lighting

The 4WP series is IP65 rated, suitable for damp and wet locations,
the fixture is ideal for outdoor walkways, entry ways, pathways,
landscapes, public areas, security lighting, etc.


Projects that feedback from our customers

60W-LED-Wall-Pack-Project-GI-Lighting

Location: Westmon IL, USA

Product: 60W LED wall pack light 98 units
