LED Post Top Retrofit Bulb

  1. LED Retrofit Kits
  2. LED Post Top Retrofit Bulb
22W LED Post Top Retrofit Kits

22W LED Post Top Retrofit Kits

/
DETAIL

Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary

 Power (W) 22W 22W 22W
Color Temperature (CCT) 4000K 4500K 5000K
Lumen Output (LM) 2,019 2,044 2,044
Efficacy (lm/W) 95 95 97
Input Voltage (V) 100-277V
Power Factor >90%
THD <20%
CRI 73
Beam Angle (°) 10°-70°
Lens Optic Lens
Dimensions (in) 3.93"Φ x 5.34"L
LED Class Nichia, UL Listed: LM80
Driver Class UL Listed: Class II
Controls Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature –25°C to +45°C
Certifications cETLus, LM79, LM80
L70 Lifetime (hours) 150,000 hours per L70 TM-21@ 25°C
Warranty 6-year limited system warranty


Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens


Nichia LED

Latest Nichia Technology chips

1.Long L90 lifetime:using Nichia's latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly.
3.Super high light efficacy.
4. Engineered with proprietary binned LM-80-rated LEDs,which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.

Innovative Optic design(Patent)

1. Meet with the Dark sky standard,no uplight.
2. Delivering light where you need it, no light waste.

 LED-POST-TOP-RETROFIT-KITS-LEDs
LED-POST-TOP-RETROFIT-KITS-LEDs-A

New Patented heat sink design

1. Adopting high quality material of high structural intensity.
2. Up and down heat sink desigh,fast the air convection.Excellent Thermal Management ensures long life.
3. Light-weight,easy to ship and install.


Installation

14 & 22W use special "X bracket", while 40W & 51W use screw-in base for easy installation.


LED-POST-TOP-RETROFIT-KITS-INSTALLATIONS

Application

• Replaces existing metal halide and HPS lamps in post top fixtures


LED-POST-TOP-RETROFIT-KITS-APPLICATIONS
