Product Description
KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.
They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.
Specificaion Summary
| Power (W) | 40W | 40W | 40W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 3,506 | 3,506 | 3,562 |
| Efficacy (lm/W) | 94 | 94 | 95 |
| Input Voltage (V) | 100-277V | ||
| Power Factor | >90% | ||
| THD | <20% | ||
| CRI | 73 | ||
| Beam Angle (°) | 10°-70° | ||
| Lens | Optic Lens | ||
| Dimensions (in) | 3.93"Φ x L9.40"L | ||
| LED Class | Nichia, UL Listed: LM80 | ||
| Driver Class | UL Listed: Class II | ||
| Controls | Dimming, Photocell, Motion sensor, Surge protection available | ||
| Operating Temperature | –25°C to +45°C | ||
| Certifications | cETLus, LM79, LM80 | ||
| L70 Lifetime (hours) | 150,000 hours per L70 TM-21@ 25°C | ||
| Warranty | 6-year limited system warranty | ||
Features
• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%
Housing & Finish
• Die-casting aluminum heat sink
• Optic Lens
Dimention
Application
• Replaces existing metal halide and HPS lamps in post top fixtures
