65W LED Shoebox

Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary

Power (W)	65W	65W	65W
Color Temperature (CCT)	4000K	4500K	5000K
Lumen Output (LM)	7,200	7,200	7,837
Efficacy (lm/W)	120	120	126
Input Voltage (V)	100-277V, 347-480V available
Power Factor	>90%
THD	<20%
CRI	73
Optics	High Purity Anodized Aluminum Reflector
Distribution	Type III, Type V available
LED Class	UL Listed: LM80
Driver Class	UL Listed: Class II
Controls	Photocell/Dimming/Motion sensors available
Environment	Wet Locations
Operating Temperature	–25°C to +45°C
Certifications	UL/cUL, LM79, LM80
L70 Lifetime (hours)	150,000 hours per L70 TM-21@ 25°C
Warranty	6-year limited system warranty standard

Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%

Controls

• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional

Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket

Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available

Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available

Optics

• Type III
• Type V

Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C

Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming

Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.

Advantages

High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.

ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.

Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional
