Product Description
KAIWIM searchlight has an excellent focused beam, with nearly parallel light rays and long range of up to 3000 meters. It is a perfect solution for applications where high visibility at a small spot is needed, such as searching operation, rescuing operation, lighting icebergs, lighting narrow channel, etc. With using only high-quality materials, it creates the best performing LED searchlight in the market.
Specification
| Power | 100W |
| Lumen Output | 6,700 LM |
| Color Temperature | 6000K |
| Beam Angle | 3.5° |
| Candlepower | 1,530,771 cd |
| Fixture Color | White( As Standard) |
| IP Rating | IP68 |
| Operating Temperature | -30°C to +40°C |
| Voltage | AC100-277V for MD & MC Types; AC110V or 220V for EC Type |
| Pan/Tilt Range | Control for MC & EC Types: Pan 0°~ 350° , Tilt -30°~ +30° |
| Warranty | 2 years for marine applications; 5 years for non-marine applications |
Note: Illumination distances are difficult to predict and deteriorate rapidly when haze, smoke, fog or smog is present.
Features
• Excellent focused optics 3.5 degree for long range illumination up to 3000m.
• Low power consumption compared to halogen/HID/MH searchlights, consuming only 75W to 240W.
• Input voltage: AC100-277V for MD & MC Types; AC110V or 220V for EC Type.
• Corrosion resistant Aluminum housing with stainless steel mounting hardware’s.
• UV-resistant toughened glass lens.
• High protection level, up to IP68, suitable for harsh weather conditions.
• High impact resistance, meeting IK10.
• High vibration resistance, meeting 3G standards.
• Low profile, lightweight, anti 17-level wind power.
• Long LED Lifespan, more than 50,000 hours, low maintenance, no bulb replacement.
• Warranty: 2 years for marine applications, 5 years for non-marine applications.
Housing & Finish
• High gloss baked white matte powder painted after fabrication
• Painted white finish
• RAL & custom colors available
Performance
| Wattage | Light Output | Beam Angle | Candlepower | illumination Distance (m) |
illumination Diameter (m) |
illumination Area (m²) |
illuminace (lux) |
| 100W | 6,700 LM | 3.5° | 1,530,771 cd | 750 | 46 | 1648 | 2.72 |
| 1000 | 61 | 2931 | 1.53 | ||||
| 1250 | 76 | 4579 | 0.98 | ||||
| 1500 | 92 | 6954 | 0.68 | ||||
| 1750 | 107 | 8975 | 0.50 |
Note: Illumination distances are difficult to predict and deteriorate rapidly when haze, smoke, fog or smog is present.
Dimensions
Operation Methods
• MD Type Manual operation - directly operated at light fixture.
• MC Type Manual operation - with adjustment column operable within the wheelhouse. (horizontally 0-350°, vertically -30 ~20°)
• EC Type Electrical operation -operated by control panel & remote controller. (horizontally 0-350°, vertically -30 ~20°)
Applications
• Searching Operation
• Rescuing Operation
• Lighting Icebergs
• Lighting Narrow Channel
