30W LED Retrofit Kits

Product Description

KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.

The 5th generation LED retrofit kits are upgraded to a more uniform and unique design with great performance enhancements. The Kits deliver over 125LPW. With best in class “Lumen per Watt Performance” one can expect maximized energy savings, it save up to 80% in electric, and eliminates your lighting maintenance for 10+ year by utilizing the highest quality LED chips, drivers, heat sinks, thermal pad, PCB boards, mounting arms, etc.

Specificaion Summary

Power (W)	30W	30W	30W
Color Temperature (CCT)	4000K	4500K	5000K
Lumen Output (LM)	3,767	3,815	3,864
Efficacy (lm/W)	128	128	128
Input Voltage (V)	100-277V
Power Factor	>93%
THD	<12%
CRI	73
Beam Angle (°)	120°
Installation	Horizontal / Vertical
Dimensions (in)	4.72″x 4.72″x1.97″
LED Class	Nichia, UL Listed: LM80
Driver Class	Meanwell, UL Listed: Class II
Controls	Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature	-35°C to 55°C
Certifications	ETL/cETL, LM79, LM80
L70 Lifetime (hours)	≥200,000 hours
Warranty	10-year limited on LED head, 5-year limited on driver

Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Optics

• Beam angle: 120° standard

Warranty

• 10-year limited on LED head, 5-year limited on driver

Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket

Qaulity Control

IQC

1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.

IQC

1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).

FQC

1. 100% appearance checking
2. 100% lable checking
3. 100% function checking

	Latest Nichia Technology chips 1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs. 2. Import from Japan Nichia directly 3.Super high light efficacy. 4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency. 5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
Real Mean Well driver One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.
	Sunon Fan Technology 1. Unique design with fan (fans) inside, more uniform structure. 2. Smaller size, almost zero noise. 3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.
New Patented heat sink design 1. Adopting AL6063 material of high structural intensity. 2. Lower profile heat sink design, more slim. 3. Flat outer surface on the heat sink, more elegant.

Application

Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation
