Product Description
KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
With various mounting brackets, the kits could retrofit a majority of fixtures whether it is a vertical or horizontal installation, eg: street light fixtures, shoebox fixtures, wall pack fixtures, flood light fixtures, canopy fixtures, and high bay fixtures, etc.
Specificaion Summary
| Power (W) | 45W | 45W | 45W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 5,700 | 5,704 | 5,713 |
| Efficacy (lm/W) | 128 | 128 | 128 |
| Input Voltage (V) | 100-277V | ||
| Power Factor | >93% | ||
| THD | <12% | ||
| CRI | 73 | ||
| Beam Angle (°) | 120° | ||
| Installation | Horizontal / Vertical | ||
| Dimensions (in) | 4.72"x 4.72"x1.97" | ||
| LED Class | Nichia, UL Listed: LM80 | ||
| Driver Class | Meanwell, UL Listed: Class II | ||
| Controls | Dimming, Photocell, Motion sensor, Surge protection available | ||
| Operating Temperature | -35°C to 55°C | ||
| Certifications | ETL/cETL, LM79, LM80 | ||
| L70 Lifetime (hours) | ≥200,000 hours | ||
| Warranty | 10-year limited on LED head, 5-year limited on driver | ||
Features• High output Nichia LEDs deliver up to 132 LPW |
Optics• Beam angle: 120° standard |
Warranty• 10-year limited on LED head, 5-year limited on driver |
|
Mountings• Horizontal Installtion: Using "L " bracket |
Qaulity Control
IQC1.Most stringent raw material selection. |
IQC1. Testing all PCB after soldering with electricity. |
FQC1. 100% appearance checking |
Mass Production
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation
