Product Description
KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.
The 5th generation LED retrofit kits are upgraded to a more uniform and unique design with great performance enhancements. The Kits deliver over 125LPW. With best in class “Lumen per Watt Performance” one can expect maximized energy savings, it save up to 80% in electric, and eliminates your lighting maintenance for 10+ year by utilizing the highest quality LED chips, drivers, heat sinks, thermal pad, PCB boards, mounting arms, etc.
Specificaion Summary
| Power (W) | 60W | 60W | 60W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 6,613 | 6,618 | 6,728 |
| Efficacy (lm/W) | 128 | 128 | 128 |
| Input Voltage (V) | 100-277V | ||
| Power Factor | >93% | ||
| THD | <12% | ||
| CRI | 73 | ||
| Beam Angle (°) | 120° | ||
| Installation | Horizontal / Vertical | ||
| Dimensions (in) | 4.72"x 4.72"x1.97" | ||
| LED Class | Nichia, UL Listed: LM80 | ||
| Driver Class | Meanwell, UL Listed: Class II | ||
| Controls | Dimming, Photocell, Motion sensor, Surge protection available | ||
| Operating Temperature | -35°C to 55°C | ||
| Certifications | ETL/cETL, LM79, LM80 | ||
| L70 Lifetime (hours) | ≥200,000 hours | ||
| Warranty | 10-year limited on LED head, 5-year limited on driver | ||
Features• High output Nichia LEDs deliver up to 132 LPW |
Optics• Beam angle: 120° standard |
Warranty• 10-year limited on LED head, 5-year limited on driver |
|
Mountings• Horizontal Installtion: Using "L " bracket |
Mass Production
Mountings
Application
Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation
