120W Shoebox LED Retrofit Kits

Product Description

120W Retrofit Kit replaces 300 Watt Metal Halide or High Pressure Sodium in your existing fixture with a simple and easy to perform retrofit process. Up to 125 lumens per watt, depending on the chosen color temperature.

Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.

Specificaion Summary

Power (W)	120W	120W	120W
Color Temperature (CCT)	4000K	4500K	5000K
Lumen Output (LM)	14,402	14,458	14,469
Efficacy (lm/W)	125	126	126
Input Voltage (V)	100-277V
Power Factor	>93%
THD	<12%
CRI	73
Beam Angle (°)	120°
Installation	Horizontal / Vertical
Dimensions (in)	6.10"x 5.12"x1.97"
LED Class	Nichia, UL Listed: LM80
Driver Class	Meanwell, UL Listed: Class II
Controls	Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature	-35°C to 55°C
Certifications	ETL/cETL, LM79, LM80
L70 Lifetime (hours)	≥200,000 hours
Warranty	10-year limited on LED head, 5-year limited on driver

Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Optics

• Beam angle: 120° standard

Warranty

• 10-year limited on LED head, 5-year limited on driver

Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket

Qaulity Control

IQC

1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.

IQC

1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).

FQC

1. 100% appearance checking
2. 100% lable checking
3. 100% function checking

Mass Production

Installation Process

How to install the DLC ETL cETL 120w LED retrofit into the traditional fixtures?

All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.

Mountings

Application

Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation

LED-retrofit-kits-application
LED-RETROFIT-KITS-FOR-PARKING-LOTS
