Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Why Use LED Retrofit Kits
LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.
LED Retrofit Kits for Open Air Parking Garage
LED Retrofit Kits for Traditional Wall Pack
Specificaion Summary
| Power (W) | 150W | 150W | 150W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 17,516 | 17,585 | 17,653 |
| Efficacy (lm/W) | 124 | 125 | 125 |
| Input Voltage (V) | 100-277V | ||
| Power Factor | >93% | ||
| THD | <12% | ||
| CRI | 73 | ||
| Beam Angle (°) | 120° | ||
| Installation | Horizontal / Vertical | ||
| Dimensions (in) | 7.87"x 5.91"x1.97" | ||
| LED Class | Nichia, UL Listed: LM80 | ||
| Driver Class | Meanwell, UL Listed: Class II | ||
| Controls | Dimming, Photocell, Motion sensor, Surge protection available | ||
| Operating Temperature | -35°C to 55°C | ||
| Certifications | ETL/cETL, LM79, LM80 | ||
| L70 Lifetime (hours) | ≥200,000 hours | ||
| Warranty | 10-year limited on LED head, 5-year limited on driver | ||
Features• High output Nichia LEDs deliver up to 132 LPW |
Optics• Beam angle: 120° standard |
Warranty• 10-year limited on LED head, 5-year limited on driver |
|
Mountings• Horizontal Installtion: Using "L " bracket |
Mass Production
Application
The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture…
