Product Description
KAIWIM LED Retrofit Kit is designed to allow cost affordable conversion from MH/HPS/HID applications to LED. They are the perfect tool for accessing the cost-savings and low maintenance of LED lighting, without replacing entire fixtures.
Retrofit kits feature a compact size to fit into all types of existing fixtures include wall pack, flood light boxes, Area Light, high-bay and Street light applications.
Why Use LED Retrofit Kits
LED Retrofit Kits allow you to reuse your existing fixtures which is a convenient and cost-effective solution while maintaining visual consistency.
LED Retrofit Kits for Open Air Parking Garage
LED Retrofit Kits for Traditional Wall Pack
Specificaion Summary
| Power (W) | 320W | 320W | 320W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 37,944 | 37,944 | 37,944 |
| Efficacy (lm/W) | 124 | 124 | 124 |
| Input Voltage (V) | 100-277V | ||
| Power Factor | >93% | ||
| THD | <12% | ||
| CRI | 73 | ||
| Beam Angle (°) | 120° | ||
| Installation | Horizontal / Vertical | ||
| Dimensions (in) | 10.63"x10.00"x2.91" | ||
| LED Class | Nichia, UL Listed: LM80 | ||
| Driver Class | Meanwell, UL Listed: Class II | ||
| Controls | Dimming, Photocell, Motion sensor, Surge protection available | ||
| Operating Temperature | -35°C to 55°C | ||
| Certifications | ETL/cETL, LM79, LM80 | ||
| L70 Lifetime (hours) | ≥200,000 hours | ||
| Warranty | 10-year limited on LED head, 5-year limited on driver | ||
Features• High output Nichia LEDs deliver up to 132 LPW |
Optics• Beam angle: 120° standard |
Warranty• 10-year limited on LED head, 5-year limited on driver |
|
Mountings• Horizontal Installtion: Using "L " bracket |
 |
Latest Nichia Technology chips 1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs. 2. Import from Japan Nichia directly |
|
Real Mean Well driver One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers. |
 |
 |
Sunon Fan Technology 1. Unique design with fan (fans) inside, more uniform structure. 2. Smaller size, almost zero noise. 3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface. |
|
New Patented heat sink design 1. Adopting AL6063 material of high structural intensity. 2. Lower profile heat sink design, more slim. 3. Flat outer surface on the heat sink, more elegant. |
 |
Installation Process
How to install the DLC ETL cETL 200w LED retrofit into the traditional fixtures?
All models are simply installed in 4 mins by Yoke bracket or the Flex bracket. ( Remark: USE A LICENSED ELECTRICIAN TO PERFORM THE INSTALLATION.)
1). Remove the plastic cover from the LED head.
2). Remove the existing component reflector and ballast inside the fixures.
3). Put the driver in the place of the previous ballast.
4). Mouning the pre-assembled bracket to the fixtures.
5). Fix the retrofit kit to the the pre-assembled bracket.
6). Connect the electric wires.
Application
The LED retrofit kits are widely used to replace the MH/HPS bulbs, Mercury lamp bulbs and Incandescent light bulbs…Below are some fixtures where the retrofit kits could be used, but not limited to:Street light fixture, high bay fixture, canopy fixture, wall pack fixture, Parking lot fixture, high mast light fixture…
