350W LED Retrofit Kits

Product Description

KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.

With various mounting brackets, the kits could retrofit a majority of fixtures whether it is a vertical or horizontal installation, eg: street light fixtures, shoebox fixtures, wall pack fixtures, flood light fixtures, canopy fixtures, and high bay fixtures, etc.

Specificaion Summary

Power (W)	350W	350W	350W
Color Temperature (CCT)	4000K	4500K	5000K
Lumen Output (LM)	42,321	41,971	43,514
Efficacy (lm/W)	121	120	125
Input Voltage (V)	100-277V
Power Factor	>93%
THD	<12%
CRI	73
Beam Angle (°)	120°
Installation	Horizontal / Vertical
Dimensions (in)	10.63"x10.00"x2.91"
LED Class	Nichia, UL Listed: LM80
Driver Class	Meanwell, UL Listed: Class II
Controls	Dimming, Photocell, Motion sensor, Surge protection available
Operating Temperature	-35°C to 55°C
Certifications	ETL/cETL, LM79, LM80
L70 Lifetime (hours)	≥200,000 hours
Warranty	10-year limited on LED head, 5-year limited on driver

Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Optics

• Beam angle: 120° standard

Warranty

• 10-year limited on LED head, 5-year limited on driver

Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket

Qaulity Control

IQC

1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.

IQC

1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).

FQC

1. 100% appearance checking
2. 100% lable checking
3. 100% function checking

Mass Production

Mountings

Application

Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation
