900W 1000W LED High Mast Lights

Product Description
Description

KAIWIM powerful 600W/900W high mast light is designed to replace 1,000W and 2,500W metal halide and high pressure sodium lights. The light output of 600W is up to 70,000lm, and 900W is 105,000lm, more energy-saving than ever.
The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique construction enables longer lifespan, almost free of maintenance.
The product is applying utility certificates, maximizing eligibility for utility rebate programs. Various options are available, including dimming, surge protection, bracket mount, 347-480V etc.

Specification Summary

Power (W)	900W	900W	900W
Color Temperature (CCT)	4000K	4500K	5000K
Lumen Output (LM)	105,000	105,000	105,000
Efficacy (lm/W)	122	122	122
Input Voltage (V)	100-277V (347-480V available)
Power Factor	>93%
CRI	≥73
IP Rate	IP66
Beam Angle (°)	Type V Std. (Type II, Type III, Type IV available)
Dimensions (in)	21.97''L x 21.38''W x 5.13''H
LED Class	Seoul 3030 SMD LEDs, UL Listed: LM80
Driver Class	Meanwell, UL Listed: Class II
Surge Protection	20kA/40kV SPD optional
Dimming	Dimming optional
Environment	Indoor or Outdoor
Operating Temperature	–35°C to +45°C
Certifications	UL/cUL, CE, RoHS, LM79, LM80
L70 Lifetime (hours)	150,000 hours
Warranty	6-year limited system warranty standard

Features

• High system efficacy up to 120 LPW
• High quality Meanwell drivers
• High quality 3030 LEDs
• IP66 rated, suitable for both indoor and outdoor areas
• Superior illumination performance, distributing lighting more uniform
• Environmentally friendly powder coatings
• Reduce energy consumption over 70%

Controls

• 0-10V dimming optional
• 20kA/40kV surge protection optional

Optics

• Type II, Type III, Type IV , Type V optional

Housing & Finish

• Die-casting aluminum heat sink
• UV resistant high quality lens
• Bronze finish standard, black and white optional
• RAL & custom colors available

Electrical

• 100-277VAC, and 347-480VAC available, 50/60Hz
• System power factor>90%
• LED driver with non-dimming or 0-10V dimming

Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available

Ratings

• IP66 waterproof
• Operating Temperature Rated at -35°C to 45°C
• Storage Temperature Rated at -45°C to 65°C

Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete informatio

Beam Angle

Advantages

Real Mean Well Driver

One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.

Structure

● Heat Sink: Air convection holes on the radiator module can accelerate air flow to achieve excellent heat dissipation radiator.
● Bracket: Adjustable angle ranges from 30° to 150°.
● Spliced Module: Standard radiator module can be connected into different wattage per customers' requirement, shorten lead time.
