55W LED Canopy Fixture High Output Garage lights Entryway Lighting

55W LED Canopy Fixture High Output Garage lights Entryway Lighting

/
DETAIL

Product Description

KAIWIM 6 th Generation LED canopy light is designed to replace metal halide/high pressure solid canopy light. It can replace 70W-250W metal halide canopy with lighting efficacy up to 142lm/w, over 70% energy saving. Optimized thermal design, separating driver from heat sink, features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C. Thoughtful construction design, allows hand free for wiring connection (for ceiling mount), provides access to driver for quick maintenance, without opening light source.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, mounting possibilities, emergency back-up, and surge protection, etc.


Specification Summary

 Power (W) 55W 55W 55W
Color Temperature (CCT) 4000K 4500K 5000K
Lumen Output (LM) 7,165 7,165 7,165
Efficacy (lm/W) 139 139 139
Voltage (V) 100-277V (347-480V available)
Power Factor >90%
THD <20%
CRI ≥73
Optics UV resistant high quality lens
Beam Angle (°) 160° Std. ( 120° available)
LED Class UL Listed: LM80
Driver Class UL Listed: Class II
Operating Temperature(°C) –25°C to 45°C
IP Rating IP65
Environment Indoor or Outdoor
Certificates UL cUL, LM79, LM80
Controls 10KA Surge Protection, Dimming, Sensors, Emergency back-up available
Life (L70, H) 150,000 hours per L70 TM-21@ 25°C
Warranty 6-year limited system warranty



Features

• High system efficacy up to 142 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Optimized thermal design, separating driver from heat sink
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%

Controls

• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up optional
• Surge protection optional

Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming

Housing & Finish

• Die-casting aluminum heat sink
• Bronze finish standard, black and white optional
• RAL & custom colors available

Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature rated at –25°C to +45°C

Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available

Warranty

• 6-year limited system warranty

Beam Angle

120°, 160° optional, UV resistant high quality lens. (Default 160°)

canopy light beam angle

Installation Options

Ceiling mount, pendant mount and quick plate mount available.

canopy-light-mounting-1

Quick Plate Mount

canopy-light-mounting-2

Pendant Mount

canopy-light-mounting-3

Ceiling Mount

Advantages of Gen.6 Canopy Light

• Unique design with elegant apperance
• Optimized thermal design features excellent heat disspation
• Unique optical lens, distributing light more uniformly on the ground
• Easy installation: hand free for wiring connection, quick maintenance
• Mounting: quick plate mount, ceiling mount, pendant mount
• Sensor: microwave sensor (compatible with remote controller), photocell
• Petents Pending: PCT patents, US patents, China patents

Applications

• Indoor & outdoor lighting
• Underground packing lot, gas station, entry way, warehouse, etc

High Output Garage lights is IP65 rated, suitable for damp and wet locations, the fixture is ideal for underground packing lot, gas station, entry way, parking garage, warehouse, storage room, sporting facilities, airplane hanger, harbor, yard, etc.
