Product Description
Product Feature:
● Dual heat dissipation design of the lamp body. Isolated aluminum heat sink and driver, hollow heat sink increase airflow.
● Increase LED plates to 10/12pcs. No lighting shadow, more luminance uniformity.
● Combined heat sink reserve gaps for more ventilation area.
● Suitable to totally enclosed fixture.
● Passed 6000V high voltage surge test, protect the lamp better.
● Good brightness LED with 130lm/w, LM80 certificated.
● More 15% LED compared with general corn bulb in market.
● Fanless design with 5 years warranty.
● The circle ring on the lamp can be customized the color as request.
● UL/cUL/DLC/CE/ROHS/FCC/LM80 certification.
● IES files available.
Product Specification:
| Watt | 75W | 100W | 120W |
| Total Lumens | 9750LM | 13000LM | 15600LM |
| Beam Angle | 360° | ||
| CCT | 3000K-6500K | ||
| Input Voltage | AC100-277V, 50-60Hz | ||
| CRI | >70 | ||
| Power Factor | >0.9 | ||
| Operating Temperature | -35℃~55℃ | ||
| IP Rating | IP64 | ||
| Test Standard | IES/LM79/LM80 | ||
| Safety Certification | UL /DLC/ CE / RoHS / FCC | ||
| Warranty Time | 5 Years | ||
Product Display:
Product Details:
Replace:
Application:
Widely used in retrofitting HPS/MH/HID/CFL as street light, garden light, industrial lightetc.
Application locations are Warehouses, Indoor and public places, and other industrial lighting purposes.
Fit for fixtures as floodlight, canopy light, highbay light, acorn, cobra head, shoebox, wallpack, post top etc.
