LED High bay Retrofit Bulb

50W 75W Highbay Retrofit Kits

50W 75W Highbay Retrofit Kits

LED retrofit design replaces MH and HPS lamps up to 400-500W. This unique design features both down and side mounted LEDs delivering a wide and uniform light distribution. Suitable for fully enclosed high bay, low bay, canopy and other area fixtures. Special separated driver and led heat sink design for better heat dissipation and good to extend the lifetime of

whole lamp.
  • 產品浮水印-02.jpg
  • 產品浮水印-03.jpg
  • 產品浮水印-04.jpg
DETAIL
Product Description

LED retrofit design replaces MH and HPS lamps up to 400-500W. This unique design features both down and side mounted LEDs delivering a wide and uniform light distribution. Suitable for fully enclosed high bay, low bay, canopy and other area fixtures. Special separated driver and led heat sink design for better heat dissipation and good to extend the lifetime of

whole lamp.


Product Feature:

●Special ventilation design, isolated gap between heat sink and driver to increase more cooling areas for better heat dissipation.

●Both down and side mounted LEDs delivering a wide and uniform light distribution.

●Suitable for totally enclosed fixtures.

●High effect lumen: 140~150lm/W.

●Driver 6000V surge protection.

●UL/cUL/DLC/CE/ROHS/FCC/LM80 certification.

●IES files, ISTMT, LM79, LM80 test reports are available.

●Fanless design with 5 years warranty.



Product Specification:

Watt 50W 75W
Total Lumens 7500LM 11250LM
Beam Angle 120°
CCT 3000K-6500K
Input Voltage AC100-277V, 50-60Hz
CRI >70
Power Factor >0.9
Operating Temperature -35℃~55℃
IP Rating IP54
Test Standard IES/LM79/LM80
Safety Certification UL /DLC/ CE / RoHS / FCC
Warranty Time 5  Years



Product Display:

Highbay Retrofit Kits

Product Details:

Highbay Retrofit Kits

Dimension & Light Distribution Curve [Unit:cd]:

Highbay Retrofit Kits



Applications:

Fit for fixtures as Retrofit replacement for conventional HID/MH/HPS lamps: Canopy Light, High bay Fixture,etc.Application locations are Warehouses, Indoor and public places, and other industrial lighting purposes.

50W 75W Highbay Retrofit Kits
