LED retrofit post top corn light is compact and mini design that can be applicable to different size of HID/MH/HPS fixtures, 360° omnidirectional lighting with high lumen up to 140~ 150lm/W.Suitable for using in the traditional post top lamp, acorn, garden light, wall way light and so on. They are UL/cUL/DLC/CE/ROHS/FCC certificated and offered 5 years warranty.
Product Feature:
●For totally enclosed fixture.
●6000V high voltage surge protection.
●High lumen effect: 150lm/W
●Retrofit for HID/MH/HPS in post top and irregular fixtures.
●UL/cUL/DLC/CE/ROHS/FCC/LM80 certification.
●IES files, ISTMT, LM79, LM80 test reports are available.
●Fanless design with 5 years warranty.
Product Specification:
Watt | 30W | 40W | 75W |
Total Lumens | 4500LM | 6000LM | 9750LM |
Beam Angle | 360° | ||
CCT | 3000K-6500K | ||
Input Voltage | AC100-277V, 50-60Hz | ||
CRI | >70 | ||
Power Factor | >0.9 | ||
Operating Temperature | -35℃~55℃ | ||
IP Rating | IP6 | ||
Test Standard | IES/LM79/LM80 | ||
Safety Certification | UL /DLC/ CE / RoHS / FCC | ||
Warranty Time | 5 Years |
Product Display:
Product Details:
Product Dimension:
Applications:
Widely used in retrofitting HPS/MH.HID/CFL lamp
Application locations as indoor and outdoor public places, other insustrial application, etc.
Fit into fixtures as post top garden light, canopy light, acorn, high bay light, etc.
