LED Street Lights

LED Street Light-KWRS-ST-06

LED Street Light-KWRS-ST-06

KAIWIN LED street light offers from 30-watt to the 150-watt, built using the ergonomically designed body to enhance the heat dissipation for the CREE 3030 chip which will deliver an impressive 130 Lumens Per Watt. This street light lamp is available in 1-10v Dimming, microwave motion sensor, photocell sensor functions.
  • 產品浮水印-01.jpg
  • 產品浮水印-04.jpg
  • 產品浮水印-05.jpg
  • 產品浮水印-06.jpg
DETAIL
Product Description
KAIWIN LED street light offers from 30-watt to the 150-watt, built using the ergonomically designed body to enhance the heat dissipation for the CREE 3030 chip which will deliver an impressive 130 Lumens Per Watt. This street light lamp is available in 1-10v Dimming, microwave motion sensor, photocell sensor functions.


Product Feature:

● Use CREE LED, high brightness 130lm/W, stable lighting performance

● Optional wattage 30W, 60W, 100W, 150W to meet different projects demands.

● Easy maintenance. Remove the driver box cover without any tools, just use your hand to twist off the key. It is convenient to repair and maintain.

● Ultra-thin streamline design, speed up the flow of wind and takes away heat.

● More function available: Photocell,1-10V dimmer, motion sensor.

● IP66 rated for external roadway illumination.

● Working environment in -35℃ to 55℃.

● CE/RoHS/LM80/IES file are available.



Product Specification:

Watt 30W 60W 100W 150W
Total Lumens 3900LM 7800LM 13000LM 19500LM
Dimension 487*200*99mm 566*290*97mm 566*290*97mm
Beam Angle 140°*60°
CCT 3000K-6000K
Input Voltage AC100-277V, 50-60Hz
CRI >80
Power Factor >0.9
Operating Temperature -35℃~55℃
IP Rating IP66
Test Standard IES/LM79/LM80
Safety Certification ETL / CE / RoHS
Warranty Time 5  Years



Product Details:

LED Street Light-R2



Beam angle:

LED Street Light-R2

Dimension:

LED Street Light-R2

Application:

Widely used for Parking Lot Lighting, Square Lighting, Roadway Lighting, Outdoor Area Lighting, High Mast Lighting, Area Lighting.

LED Street Light-R2
