KAIWIN LED street light offers from 30-watt to the 150-watt, built using the ergonomically designed body to enhance the heat dissipation for the CREE 3030 chip which will deliver an impressive 130 Lumens Per Watt. This street light lamp is available in 1-10v Dimming, microwave motion sensor, photocell sensor functions.
Product Feature:
● Use CREE LED, high brightness 130lm/W, stable lighting performance
● Optional wattage 30W, 60W, 100W, 150W to meet different projects demands.
● Easy maintenance. Remove the driver box cover without any tools, just use your hand to twist off the key. It is convenient to repair and maintain.
● Ultra-thin streamline design, speed up the flow of wind and takes away heat.
● More function available: Photocell,1-10V dimmer, motion sensor.
● IP66 rated for external roadway illumination.
● Working environment in -35℃ to 55℃.
● CE/RoHS/LM80/IES file are available.
Product Specification:
| Watt | 30W | 60W | 100W | 150W |
| Total Lumens | 3900LM | 7800LM | 13000LM | 19500LM |
| Dimension | 487*200*99mm | 566*290*97mm | 566*290*97mm | |
| Beam Angle | 140°*60° | |||
| CCT | 3000K-6000K | |||
| Input Voltage | AC100-277V, 50-60Hz | |||
| CRI | >80 | |||
| Power Factor | >0.9 | |||
| Operating Temperature | -35℃~55℃ | |||
| IP Rating | IP66 | |||
| Test Standard | IES/LM79/LM80 | |||
| Safety Certification | ETL / CE / RoHS | |||
| Warranty Time | 5 Years | |||
Product Details:
Beam angle:
Dimension:
Application:
Widely used for Parking Lot Lighting, Square Lighting, Roadway Lighting, Outdoor Area Lighting, High Mast Lighting, Area Lighting.
