KAIWIM LED LED Street Light is designed to offer better security, more lumens, and higher cost savings. Using up to 70% less power over traditional metal halide or high pressure sodium lighting. This product is optimal for retrofit installations or new construction installations.
Product Feature:
● Use CREE LED, high brightness 130lm/W, stable lighting performance
● High reliable LED driver results in energy savings upto 65%● Choose between T2/T3/T4 light distributions
● Photocell and motion sensor are available
● IP65 rated for external roadway illumination
● Working environment in -35℃ to 55℃.
● Easy installation and maintenance
● 5 years warranty with >50,000 hours lifespan
● CE/RoHS/LM80/IES file are available.using for better anti-corrosion.
● ETL/DLC/CE/RoHS/LM79/LM80/IES for quality assurance and safe operation.
Product Specification:
| Watt | 50W | 100W | 150W | 200W |
| Total Lumens | 6500LM | 13000LM | 19500LM | 26000LM |
| Dimension | 483*230*127mm | 548*230*127mm | 598*257*129mm | 655*320*122mm |
| Beam Angle | TYPE2 / TYPE3 / TYPE4 | |||
| LED Brand | CREE 3030 | |||
| CCT | 2700K-6500K | |||
| Input Voltage | AC100-277V, 50-60Hz | |||
| CRI | Ra>70 | |||
| Power Factor | >0.9 | |||
| Surge Voltage | 4KV; 20KV optional | |||
| Operating Temperature | -35℃~55℃ | |||
| IP Rating | IP65 | |||
| Safety Certification | CE/RoHS/LM80/IES | |||
| Warranty Time | 5 Years | |||
Product Details:
Dimension:
Beam Angle:
|
Type II The Type II distribution is used for wide walkways, on ramps and entrance roadways, as well as other long, narrow lighting. This type is meant for lighting larger areas and usually is located near the roadside. You'll find this type of lighting mostly on smaller side streets or jogging paths. |
 |
| Type III The Type III distribution is meant for roadway lighting, general parking areas and other areas where a larger area of lighting is required. Type III lighting needs to be placed to the side of the area, allowing the light to project outward and fill the area. This produces a filling light flow. |
 |
| Type IV The Type IV distribution produces a semicircular light meant for mounting on thesides of buildings and walls. It's best for illuminating the perimeter of parkingareas and businesses. |
 |
Application:
Widely used for Parking Lot Lighting, Square Lighting, Roadway Lighting, Outdoor Area Lighting,
High Mast Lighting, Area Lighting.
