KAIWIM LED Street Light is perfect replacement for traditional lights, it can save up to 80% electricity cost, better efficiency, longer lifespan. It is IP66 waterproof rating for roadway
lighting with good water and weather resistance. Come with optically optimized PC lenses, uniformity in light distribution.
Product Feature:
● Use CREE LED, high brightness 130lm/W, stable lighting performance
● High reliable LED driver results in energy savings up to 65%
●Choose between T3 and T4 beam angles
●Photocell and motion sensor are available
● IP66 rated for external roadway illumination.
●Working environment in -35℃ to 55℃.
● Easy installation and maintenance
●5 years warranty with >50,000 hours lifespan
●CE/RoHS/LM80/IES file are available.
Product Specification:
Watt | 50W | 100W | 150W |
Total Lumens | 6500LM | 13000LM | 19500LM |
Dimension | 229*407*105mm | 229*508*105mm | 566*290*97mm |
Beam Angle | T3/T4 | ||
CCT | 2700K-6500K | ||
Input Voltage | AC100-277V, 50-60Hz | ||
CRI | Ra>70 | ||
Power Factor | >0.9 | ||
Operating Temperature | -35℃~55℃ | ||
IP Rating | IP66 | ||
Safety Certification | CE/RoHS/LM80/IES | ||
Warranty Time | 5 Years |
Product Details:
Beam Angle:
Type III The Type III distribution is meant for roadway lighting, general parking areas and other areas where a larger area of lighting is required. Type III lighting needs to be placed to the side of the area, allowing the light to project outward and fill the area. This produces a filling light flow. |
|
Type IV The Type IV distribution produces a semicircular light meant for mounting on thesides of buildings and walls. It's best for illuminating the perimeter of parkingareas and businesses. |
Application:
Widely used for Parking Lot Lighting, Square Lighting, Roadway Lighting, Outdoor Area Lighting,
High Mast Lighting, Area Lighting.
