Product Description
Product Feature:

●Meanwell LED Drivers, AC100V~277V, PF>0.98, THD<15%.
●30°/ 60°/ 90°x135° beam angles and excellent uniformity.
●Ultra-low luminous decay <10% in 5 years. L70>50,000hrs.
●Junction temperature<70°C, good heat dissipation provide longer lifetime.
●Light transmittance of PC more than 93%.
●Intelligent dimming system. 0-10V, DMX and DALI dimming models are available.
●IP67 rating is applicable to outdoor environment.
●Working environment in -35℃ to 55℃.
●ETL/cETL/DLC/CE/RoHS/SAA/LM79/LM80/IES file is available.
●50000 hours lifespan with 5 year warranty.



Product Specification:




Watt
100W
200W
300W
400W
600W
800W
1000W
1200W


Total Lumens
15000LM
30000LM
45000LM
60000LM
90000LM
120000LM
150000LM
180000LM


Beam Angle
30°/60°/90°/120°


CCT
3000K-6500K


Input Voltage
90-305V, 50-60Hz


CRI
>70


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP67


Test Standard
IES/LM79/LM80


Safety Certification
ETL / cETL /DLC/ CE / RoHS / FCC /


Warranty Time
5  Years






Product Display:





Product Details:
Frame & Optical Technology

1. Aluminium alloy heatsink with electrophoresis treatment, corrosion resistant powder coated finish.

2. Stainless steel bracket, can bear the weight of 8 times lamp.

3. Japan advance calculus optical lens-PC leds.

Cooling Technology
1.With 4D heat dissipation technology, with large large cooling area.
2.Good cooling system can extend the lifespan in harsh envionment.




Application:

Applied in large sports field lighting, football, basketball, golf and tennis court, racetrack, badminton, roads, high-rise buildings, tower lights, etc.

Can also be applied in large square, airport, commercial building, construction engineering, farm, amusement parks, parking lots, harbor, industrial buildings, and other special lighting environment.

Product Description
Product Feature:

●Using LUMILEDS 5050, high lumen efficient reach to 150lm/w.
●Meanwell driver provide superior performance,separate driver box design,better for heat dissipation and maintenance.
●Various beam angle 10°,25°,45°,60° are available for optional,more uniform light distribution.
●Lamp cap available, avoid the light glare.
●Power treatment surface, better protection from fading, rusty and direct sunlight.
●Three kinds bracket meet different installation environment.
●IP67 rating is applicable to outdoor environment.
●Working environment in -35℃ to 55℃.
●ETL/cETL/CE/RoHS/LM80/LM79/IES file are available.
●More than 50,000 hours lifespan with 5 years warranty.

Product Specification:




Watt
400W
500W
600W
750W
800W
1000W
1200W


Total Lumens
60000LM
75000LM
90000LM
112500LM
120000LM
150000LM
180000LM


Beam Angle
10°/25°/45°/60°


CCT
3000K-6500K


Input Voltage
90-305V, 50-60Hz


CRI
>70


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP67


Test Standard
IES/LM79/LM80


Safety Certification
ETL / cETL / CE / RoHS / FCC /


Warranty Time
5  Years






Product Display:





Product Details:



3 Types Of Bracket:





Application:

Applied in large sports field lighting, football, basketball, golf and tennis court, racetrack, badminton, roads, high-rise buildings, tower lights, etc.

Can also be applied in large square, airport, commercial building, construction engineering, farm, amusement parks, parking lots, harbor, industrial buildings, and other special lighting environment.

High performance output, low profile KWRS-SPFL-03 led flood light utilizing Philips Lumileds LED and Meanwell driver, offering 100w~1200w for choice. High lumens can up to 150 lumen per watt, Available in 20°/40°/60°/90° multiple optical lenses for sports venuse and large areas
