Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.




Specification Summary








 Power (W)
300W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
38,486


Efficacy (lm/W)
128


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
13.7kgs / 30.2 lbs


Dimensions (in)
Φ377mm  × L172mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV or 40KV


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version









Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam

Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.



Specification Summary








 Power (W)
400W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
50,520


Efficacy (lm/W)
126


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
14kgs / 30.9 lbs


Dimensions (in)
Φ377mm  × L172mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV SPD standard (40KV optional)


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version











Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam

Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.


Specification Summary








 Power (W)
500W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
56,614


Efficacy (lm/W)
115


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
14.1 kgs / 31.1 lbs


Dimensions (in)
Φ377mm  × L172mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV or 40KV


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version









Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam

Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.



Specification Summary








 Power (W)
600W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
76,819


Efficacy (lm/W)
128


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
19.4 kgs / 42.8 lbs


Dimensions (in)
Φ477mm  × L174mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV or 40KV


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version










Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam



Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.



Specification Summary








 Power (W)
750W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
84,374


Efficacy (lm/W)
115


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
19.5 kgs / 43 lbs


Dimensions (in)
Φ477mm  × L174mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV or 40KV


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version










Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam



Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.



Specification Summary








 Power (W)
950W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
115,344


Efficacy (lm/W)
122


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
27 kgs / 59.5 lbs


Dimensions (in)
Φ531mm  × L172mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV or 40KV


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version










Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam



Product Description

KAIWIM powerful LED high mast light is designed to replace high power traditional lighting products, such as Metal Halide, High Pressure Sodium light, High Intensity Discharge Lamp, etc., available in 300W, 400W, 500W, 600W, 750W, 950W, 1200W, replacing MH/HPS/HID from 600W to 3500W. The light output is up to 125lm/w, more energy-saving than ever.

The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique heat dissipation structure makes it much better cooling system than other competitives, enables longer lifespan, almost free of maintenance.

Specification Summary








 Power (W)
1200W


Color Temperature (CCT)
3000K/4000K/5000K/5700K/6500K (others available)


Lumen Output (LM)
134,087


Efficacy (lm/W)
118


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>95%


CRI
≥70Ra, or ≥90Ra


Gross Weight
28 kgs / 61.7 lbs


Dimensions (in)
Φ531mm  × L172mm


IP Rating
IP67


IK Rating
IK10 (High impact resistance)


Anti-wind Test
Withstand class 17 typhoon


Beam Angle (°)
16°, 40°, 60°, 90°, Type III, Type V optional


Driver Brand
Meanwell


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


SPD
20KV or 40KV


Photocontrol
Twist-lock photocell available


Dimming Options
0-10V dimming / Zigbee wireless dimming available


Zigbee Control
On/off, dimming, color turning, grouping, status monitoring, remote control etc (via APP)


DMX Control
DMX512 control available


Environment
Indoor or outdoor


Operating Temperature
–40°C- 40°C / -40°F - 104°F


Certifications
UL/cUL, CB, CE, ENEC, ROHS approved.
(PSE/RCM/SAA/EAC/KC/BIS/Inmetro/TISI/NOM/SASO COC pending)


L70 Lifetime (hours)
>100,000 Hrs (L70 @ 25°C)


Warranty
7-year warranty for 100-277V version, 5-year warranty for 347-480V version









Features

● High Protection Level up to IP67

Light engines and driver compartment are sealed to protect LEDs, electrical components, and terminal block against dust and moisture, increasing reliability and extending lifespan.

● High Impact Resistance

Meets IK10 mechanics impact protection code.

● Anti 17-level Wind Power

Fixture’s Low profile and pin structure effectively reduce wind load, plus light weight and high mechanics strength, the fixture has strong ability of anti-wind.

● High Vibration Resistance

Meets ANSI C136.31-2001 3G bridge and overpass vibration standards.


● Surge Suppression Protection

Optional 20KV or 40KV SPD for adding an additional layer of protection for the light.

● HD TV Broadcasting

High lumen efficiency, flicker free, and options of CRI>90, TLCI>90, meeting the lighting requirements of HD TV broadcasting for sports events.

● Intelligent Control

Intelligent Zigbee controller, supports wireless on/off, dimming, color turning, grouping, status monitoring, remote control, all simply and easily via smart-phone.

● Twist-lock Photocontrol

Optional twist-lock photocell at the back, can be quickly upgraded in the future.




Beam Angle

Optics of this 1200W version are 16°, 40°, 60° optional. A variety of lighting distributions, UV stabilized materials, meeting demands of various applications. Widely used for both indoor and outdoor, including stadium, high mast pole, airport, roadway, etc..










Wattage
  Beam Angle
  NEMA Angle


  300W-500W
16°
3H3V


  300W-500W
40°
4H4V


  300W-500W
60°
5H5V


  300W-500W
90°
6H6V


  600W-750W
16°
3H3V


  600W-750W
40°
4H4V


  600W-750W
60°
5H5V


 950W-1200W
16°
3H3V


 950W-1200W
40°
4H4V


 950W-1200W
60°
5H5V






Extraordinary Thermal Management

The professional and unique pin heat sink design creates superb ventilative efficiency. Air is freely flowable among the pins in any direction, maximizing heat dissipation and lifespan of the LEDs.

Advantage of our pin heatsink: Incoming air from any direction moves approximately straight forward through the pins, bringing away heat quickly. Comparing to other typical radiant-fin heatsink, incoming air is deflected and slowed down by the radiant fins, moving heat slowly.


High Thermal Conductivity

We use A1070 pure Aluminum, with 223 w/m.k thermal conductivity (VS. Typical ADC12 Aluminum with only 98 w/m.k)


Slim and Lightweight

Optimized engineered design, slim and lightweight, no clunky components, significantly reducing shipping and labor, and safer to use on your existing infrastructure.


Dimensions





300W / 400W / 500W



600W / 750W



950W / 1200W




Easy Installation

Mounting angle adjustable up to 270°. Suitable for vertical mount / horizontal mount to pole devices, and ceiling mount.





Horizontal Mount



Vertical Mount



Ceiling Mount




Applications

1) Sports lighting applications: outdoor and indoor sports arenas and stadiums, indoor sports halls, etc.
2) High mast flood lighting applications: expressways merge or intersect, airport, shipping terminals, heavy-industry zones, Plazas, prison yards,etc.

Projects that feedback from our customers

Application: Outdoor area high mast pole
Location: Saudi Arabia

Application: Water Golf Course
Location: Vietnam



Product Description

KAIWIM powerful 600W/900W high mast light is designed to replace 1,000W and 2,500W metal halide and high pressure sodium lights. The light output of 600W is up to 70,000lm, and 900W is 105,000lm, more energy-saving than ever.
The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique construction enables longer lifespan, almost free of maintenance.
The product is applying utility certificates, maximizing eligibility for utility rebate programs. Various options are available, including dimming, surge protection, bracket mount, 347-480V etc.

Specification Summary










 Power (W)
600W
600W
600W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
70,000
70,000
70,000


Efficacy (lm/W)
120
120
120


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>93%


CRI
≥73


IP Rate
IP66


Beam Angle (°)
Type V Std. (Type II, Type III, Type IV available)


Dimensions (in)
21.97''L x 14.22''W x 5.13''H


LED Class
Seoul 3030 SMD LEDs, UL Listed: LM80


Driver Class
Meanwell, UL Listed: Class II


Surge Protection
20kA/40kV SPD optional


Dimming
Dimming optional


Environment
Indoor or Outdoor


Operating Temperature
–35°C to +45°C


Certifications
UL/cUL, CE, RoHS, LM79, LM80


L70 Lifetime (hours)
150,000 hours


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 120 LPW
• High quality Meanwell drivers
• High quality 3030 LEDs
• IP66 rated, suitable for both indoor and outdoor areas
• Superior illumination performance, distributing lighting more uniform
• Environmentally friendly powder coatings
• Reduce energy consumption over 70%


Controls

• 0-10V dimming optional
• 20kA/40kV surge protection optional




Optics

• Type II, Type III, Type IV , Type V optional


Housing & Finish

• Die-casting aluminum heat sink
• UV resistant high quality lens
• Bronze finish standard, black and white optional
• RAL & custom colors available




Electrical

• 100-277VAC, and 347-480VAC available, 50/60Hz
• System power factor>90%
• LED driver with non-dimming or 0-10V dimming


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Ratings

• IP66 waterproof
• Operating Temperature Rated at -35°C to 45°C
• Storage Temperature Rated at -45°C to 65°C


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete informatio





Beam Angle






Advantages


Real Mean Well Driver

One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.

Structure

● Heat Sink: Air convection holes on the radiator module can accelerate air flow to achieve excellent heat dissipation radiator.
● Bracket: Adjustable angle ranges from 30° to 150°.
● Spliced Module: Standard radiator module can be connected into different wattage per customers' requirement, shorten lead time.


Dimension



Installation Options

Yoke bracket (others customizable)




Applications

• Indoor & outdoor lighting
• Sports field, airport area, roadway, warehouse, high mast pole, etc.

It is IP66 rate and can be widely used for both indoor and outdoor areas, including warehouse, stadium, high mast pole, port, etc.

Product Description
Description

KAIWIM powerful 600W/900W high mast light is designed to replace 1,000W and 2,500W metal halide and high pressure sodium lights. The light output of 600W is up to 70,000lm, and 900W is 105,000lm, more energy-saving than ever.
The compact design makes shipping and installation much easier. And excellent thermal management with cold-forging heat sink and unique construction enables longer lifespan, almost free of maintenance.
The product is applying utility certificates, maximizing eligibility for utility rebate programs. Various options are available, including dimming, surge protection, bracket mount, 347-480V etc.

Specification Summary










 Power (W)
900W
900W
900W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
105,000
105,000
105,000


Efficacy (lm/W)
122
122
122


Input Voltage (V)
100-277V (347-480V available)


Power Factor
>93%


CRI
≥73


IP Rate
IP66


Beam Angle (°)
Type V Std. (Type II, Type III, Type IV available)


Dimensions (in)
21.97''L x 21.38''W x 5.13''H


LED Class
Seoul 3030 SMD LEDs, UL Listed: LM80


Driver Class
Meanwell, UL Listed: Class II


Surge Protection
20kA/40kV SPD optional


Dimming
Dimming optional


Environment
Indoor or Outdoor


Operating Temperature
–35°C to +45°C


Certifications
UL/cUL, CE, RoHS, LM79, LM80


L70 Lifetime (hours)
150,000 hours


Warranty
6-year limited system warranty standard










Features

• High system efficacy up to 120 LPW
• High quality Meanwell drivers
• High quality 3030 LEDs
• IP66 rated, suitable for both indoor and outdoor areas
• Superior illumination performance, distributing lighting more uniform
• Environmentally friendly powder coatings
• Reduce energy consumption over 70%


Controls

• 0-10V dimming optional
• 20kA/40kV surge protection optional




Optics

• Type II, Type III, Type IV , Type V optional


Housing & Finish

• Die-casting aluminum heat sink
• UV resistant high quality lens
• Bronze finish standard, black and white optional
• RAL & custom colors available




Electrical

• 100-277VAC, and 347-480VAC available, 50/60Hz
• System power factor>90%
• LED driver with non-dimming or 0-10V dimming


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Ratings

• IP66 waterproof
• Operating Temperature Rated at -35°C to 45°C
• Storage Temperature Rated at -45°C to 65°C


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete informatio





Beam Angle






Advantages


Real Mean Well Driver

One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.

Structure

● Heat Sink: Air convection holes on the radiator module can accelerate air flow to achieve excellent heat dissipation radiator.
● Bracket: Adjustable angle ranges from 30° to 150°.
● Spliced Module: Standard radiator module can be connected into different wattage per customers' requirement, shorten lead time.


Dimension



Installation Options

Yoke bracket (others customizable)




Applications

• Indoor & outdoor lighting
• Sports field, airport area, roadway, warehouse, high mast pole, etc.

It is IP66 rate and can be widely used for both indoor and outdoor areas, including warehouse, stadium, high mast pole, port, etc.

Product Description
Product Name: 400w LED Stadium Lighting

Specifications:





Power:


400W




Working voltage:


AC90-305V, 50/60Hz;




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

105-110LM/W



Beam Angle:


25°, 45°, 60°, 90°, 100°, 30*90°, 60*90°




IP Rate:

IP65



CONFIGURATIONS




LED chip:


CREE XTE




LED driver:


Mean Well




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


CE, RoHS, FCC





Application:

Widely used for lighting for tower, high-rise building, construction site, stadium, sculpture, football field, golf court, dock, etc;

Product Description
Product Name: 500w LED Stadium Lighting

Specifications:





Power:


500W




Working voltage:


AC90-305V, 50/60Hz;




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

105-110LM/W



Beam Angle:


25°, 45°, 60°, 90°, 100°, 30*90°, 60*90°




IP Rate:

IP65



CONFIGURATIONS




LED chip:


CREE XTE




LED driver:


Mean Well




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


CE, RoHS, FCC





Application:

Widely used for lighting in sports field, especially in football field, high-rise building, construction site, sculpture, dock, airport, etc;

Product Description
PRODUCT SPECIFICATIONS




Product name:


1000w LED stadium lighting




Power:


1000W




Working voltage:


AC90-305V, 50/60Hz




PF:


> 0.97




IP Grade:


IP65




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Light Efficiency:


100-110lm/w




View angle:


10*90°, 50*90°




CONFIGURATIONS




LED chip:


440PCS CREE XTE




LED driver:


Mean Well




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-30℃  to  50℃




Storage Temperature:


-30℃  to  60℃




Net Weight:


31.5KGS




Gross Weight:


35.0KGS




Packing size:


81*63*63CM




Warranty:


5 Years




Certificates:


CE, RoHS, FCC





Application:

Best solution for golf court, football court, tennis court, stadium, dock, etc.
