Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary










 Power (W)
65W
65W
65W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
7,200
7,200
7,837


Efficacy (lm/W)
120
120
126


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard








Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary




 Power (W)
105W
105W
65W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
11,600
11,600
11,600


Efficacy (lm/W)
121
121
121


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary




 Power (W)
140W
140W
140W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
16,000
16,000
16,000


Efficacy (lm/W)
123
123
123


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary




 Power (W)
210W
210W
210W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
25,300
25,300
25,300


Efficacy (lm/W)
120
120
120


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary










 Power (W)
300W
300W
300W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
35,000
35,000
35,000


Efficacy (lm/W)
121
121
121


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




75W/100W perfect replacement lamp, widely used for shoebox, flood light, street light these totally enclosed fixtures. Internal driver without Fan design with 5 years warranty. E39/EX39/E40 base, the lighting angle is adjustable 180°/270°according to the applications. The lamp is high brightness with 150lm/w, LM80 standard LED. The whole series are UL DLC certificated. IES files are available.
