Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary










 Power (W)
15W
15W
15W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
1,321
1,321
1,339


Efficacy (lm/W)
93
93
95


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
3.93"Φ x 5.34"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens







Latest Nichia Technology chips

1.Long L90 lifetime:using Nichia's latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly.
3.Super high light efficacy.
4. Engineered with proprietary binned LM-80-rated LEDs,which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




Innovative Optic design(Patent)

1. Meet with the Dark sky standard,no uplight.
2. Delivering light where you need it, no light waste.






New Patented heat sink design

1. Adopting high quality material of high structural intensity.
2. Up and down heat sink desigh,fast the air convection.Excellent Thermal Management ensures long life.
3. Light-weight,easy to ship and install.






Installation

14 & 22W use special "X bracket", while 40W & 51W use screw-in base for easy installation.


Application

• Replaces existing metal halide and HPS lamps in post top fixtures

Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary




 Power (W)
22W
22W
22W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
2,019
2,044
2,044


Efficacy (lm/W)
95
95
97


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
3.93"Φ x 5.34"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens







Latest Nichia Technology chips

1.Long L90 lifetime:using Nichia's latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly.
3.Super high light efficacy.
4. Engineered with proprietary binned LM-80-rated LEDs,which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




Innovative Optic design(Patent)

1. Meet with the Dark sky standard,no uplight.
2. Delivering light where you need it, no light waste.






New Patented heat sink design

1. Adopting high quality material of high structural intensity.
2. Up and down heat sink desigh,fast the air convection.Excellent Thermal Management ensures long life.
3. Light-weight,easy to ship and install.






Installation

14 & 22W use special "X bracket", while 40W & 51W use screw-in base for easy installation.


Application

• Replaces existing metal halide and HPS lamps in post top fixtures




Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary










 Power (W)
40W
40W
40W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
3,506
3,506
3,562


Efficacy (lm/W)
94
94
95


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
3.93"Φ x L9.40"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens

Dimention


Application

• Replaces existing metal halide and HPS lamps in post top fixtures

Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary










 Power (W)
56W
56W
56W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
4,805
4,805
4,862


Efficacy (lm/W)
96
96
97


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
Φ3.86"Φ x L10.58"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens

Dimention


Application

• Replaces existing metal halide and HPS lamps in post top fixtures

LED retrofit post top corn light is compact and mini design that can be applicable to different size of HID/MH/HPS fixtures, 360° omnidirectional lighting with high lumen up to 140~ 150lm/W.Suitable for using in the traditional post top lamp, acorn, garden light, wall way light and so on. They are UL/cUL/DLC/CE/ROHS/FCC certificated and offered 5 years warranty.

LED retrofit post top corn light is compact and mini design that can be applicable to different size of HID/MH/HPS fixtures, 360° omnidirectional lighting with high lumen up to 140~ 150lm/W.Suitable for using in the traditional post top lamp, acorn, garden light, wall way light and so on. They are UL/cUL/DLC/CE/ROHS/FCC certificated and offered 5 years warranty.
