Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary










 Power (W)
15W
15W
15W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
1,321
1,321
1,339


Efficacy (lm/W)
93
93
95


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
3.93"Φ x 5.34"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens







Latest Nichia Technology chips

1.Long L90 lifetime:using Nichia's latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly.
3.Super high light efficacy.
4. Engineered with proprietary binned LM-80-rated LEDs,which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




Innovative Optic design(Patent)

1. Meet with the Dark sky standard,no uplight.
2. Delivering light where you need it, no light waste.






New Patented heat sink design

1. Adopting high quality material of high structural intensity.
2. Up and down heat sink desigh,fast the air convection.Excellent Thermal Management ensures long life.
3. Light-weight,easy to ship and install.






Installation

14 & 22W use special "X bracket", while 40W & 51W use screw-in base for easy installation.


Application

• Replaces existing metal halide and HPS lamps in post top fixtures

Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary




 Power (W)
22W
22W
22W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
2,019
2,044
2,044


Efficacy (lm/W)
95
95
97


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
3.93"Φ x 5.34"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens







Latest Nichia Technology chips

1.Long L90 lifetime:using Nichia's latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.
2. Import from Japan Nichia directly.
3.Super high light efficacy.
4. Engineered with proprietary binned LM-80-rated LEDs,which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




Innovative Optic design(Patent)

1. Meet with the Dark sky standard,no uplight.
2. Delivering light where you need it, no light waste.






New Patented heat sink design

1. Adopting high quality material of high structural intensity.
2. Up and down heat sink desigh,fast the air convection.Excellent Thermal Management ensures long life.
3. Light-weight,easy to ship and install.






Installation

14 & 22W use special "X bracket", while 40W & 51W use screw-in base for easy installation.


Application

• Replaces existing metal halide and HPS lamps in post top fixtures




Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary










 Power (W)
40W
40W
40W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
3,506
3,506
3,562


Efficacy (lm/W)
94
94
95


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
3.93"Φ x L9.40"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens

Dimention


Application

• Replaces existing metal halide and HPS lamps in post top fixtures

Product Description

KAIWIM LED Post Top Retrofit Kits are an energy-efficient and perfect solution for replacing traditional metal halides and high pressure sodium sources in post top fixtures.
With excellent optical design, it can reduce light pollution by eliminating upward light emission. Lamp includes an external UL LED driver for better thermal management ensures long life. 14W & 22W use special “X bracket”, while 40W & 56W use screw-in base for easy installation.

They are rated for a long 100,000-hour lifespan and are backed by Green Inova’s 6-year limited warranty.


Specificaion Summary










 Power (W)
56W
56W
56W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
4,805
4,805
4,862


Efficacy (lm/W)
96
96
97


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Beam Angle (°)
10°-70°


Lens
Optic Lens


Dimensions (in)
Φ3.86"Φ x L10.58"L


LED Class
Nichia, UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
–25°C to +45°C


Certifications
cETLus, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty





Features

• High output Nichia LEDs deliver up to 97 LPW
• External UL LED driver to ensure reliability and performance
• Die-casting aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• Over temperature protection system
• Innovative optic design, significantly reduces upward light
• Compliance to Dark Sky requirement
• Quick and easy installation
• Reduces energy and maintenance costs over 80%

Housing & Finish

• Die-casting aluminum heat sink
• Optic Lens

Dimention


Application

• Replaces existing metal halide and HPS lamps in post top fixtures

Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary










 Power (W)
65W
65W
65W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
7,200
7,200
7,837


Efficacy (lm/W)
120
120
126


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard








Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary




 Power (W)
105W
105W
65W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
11,600
11,600
11,600


Efficacy (lm/W)
121
121
121


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary




 Power (W)
140W
140W
140W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
16,000
16,000
16,000


Efficacy (lm/W)
123
123
123


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary




 Power (W)
210W
210W
210W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
25,300
25,300
25,300


Efficacy (lm/W)
120
120
120


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description

KAIWIM Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.

Specification Summary










 Power (W)
300W
300W
300W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
35,000
35,000
35,000


Efficacy (lm/W)
121
121
121


Input Voltage (V)
100-277V, 347-480V available


Power Factor
>90%


THD
<20%


CRI
73


Optics
High Purity Anodized Aluminum Reflector


Distribution
Type III, Type V available


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Photocell/Dimming/Motion sensors available


Environment
Wet Locations


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%


Controls
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional



Mounting Bracket

• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket




Housing & Finish

• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• Type III
• Type V


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.






Advantages






High Quality LED Chips

1.Top brand high quality chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




ADC 12 Die-cast Aluminium Heat Sink

1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.

Lighting distribution

Type III, Type V optional.






Multifunctions

1. 0-10V dimming optional
2. Photocell sensor optional
3. Dimming motion sensor optional
4. Remote controller optional
5. Surge protector (over current device) optional






Mounting Brackets Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket






Installation Options












Slip Fitter


Straight Arm


Trunnion Bracket


Yoko Bracket










Applications

• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.

LED Shoebox series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.







Projects that feedback from our customers

Location: Mississippi, USA
Product: 140W LED Shoebox Light




Product Description



KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.

The 5th generation LED retrofit kits are upgraded to a more uniform and unique design with great performance enhancements. The Kits deliver over 125LPW. With best in class “Lumen per Watt Performance” one can expect maximized energy savings, it save up to 80% in electric, and eliminates your lighting maintenance for 10+ year by utilizing the highest quality LED chips, drivers, heat sinks, thermal pad, PCB boards, mounting arms, etc.



Specificaion Summary




 Power (W)
30W
30W
30W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
3,767
3,815
3,864


Efficacy (lm/W)
128
128
128


Input Voltage (V)
100-277V


Power Factor
>93%


THD
<12%


CRI
73


Beam Angle (°)
120°


 Installation
Horizontal / Vertical


Dimensions (in)
4.72″x 4.72″x1.97″


LED Class
Nichia, UL Listed: LM80


Driver Class
Meanwell, UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
-35°C to 55°C


Certifications
ETL/cETL, LM79, LM80


L70 Lifetime (hours)
≥200,000 hours


Warranty
10-year limited on LED head, 5-year limited on driver









Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%


Optics

• Beam angle: 120° standard




Warranty

• 10-year limited on LED head, 5-year limited on driver




Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket









Qaulity Control





IQC

1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.


IQC

1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).


FQC

1. 100% appearance checking
2. 100% lable checking
3. 100% function checking












Latest Nichia Technology chips

1.Long L90 lifetime: using Nichia' s latest LED technology, the L90 life is 60% longer than Philips 3030 LEDs.

2. Import from Japan Nichia directly
3.Super high light efficacy.
4.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
5.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




Real Mean Well driver

One of our subsidiary corporations is a Mean Well distributor, allowing us quality source for Mean well drivers.






Sunon Fan Technology

1. Unique design with fan (fans) inside, more uniform structure.

2. Smaller size, almost zero noise.

3. 70,000+ hour operating life suitable for 24/7 operation, providing an exceptionally cool running LED unit, efficiently transferring the heat from the heat sink to the outer surface.




New Patented heat sink design

1. Adopting AL6063 material of high structural intensity.

2. Lower profile heat sink design, more slim.

3. Flat outer surface on the heat sink, more elegant.







Application

Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation

Product Description



KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.

With various mounting brackets, the kits could retrofit a majority of fixtures whether it is a vertical or horizontal installation, eg: street light fixtures, shoebox fixtures, wall pack fixtures, flood light fixtures, canopy fixtures, and high bay fixtures, etc.



Specificaion Summary










 Power (W)
45W
45W
45W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
5,700
5,704
5,713


Efficacy (lm/W)
128
128
128


Input Voltage (V)
100-277V


Power Factor
>93%


THD
<12%


CRI
73


Beam Angle (°)
120°


 Installation
Horizontal / Vertical


Dimensions (in)
4.72"x 4.72"x1.97"


LED Class
Nichia, UL Listed: LM80


Driver Class
Meanwell, UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
-35°C to 55°C


Certifications
ETL/cETL, LM79, LM80


L70 Lifetime (hours)
≥200,000 hours


Warranty
10-year limited on LED head, 5-year limited on driver









Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%


Optics

• Beam angle: 120° standard




Warranty

• 10-year limited on LED head, 5-year limited on driver




Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket









Qaulity Control





IQC

1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.


IQC

1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing
3. Waterproof testing
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).


FQC

1. 100% appearance checking
2. 100% lable checking
3. 100% function checking





Mass Production




Mountings

Application

Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation

Product Description



KAIWIM 5th generation LED retrofit kit is an innovative and revolutionary product. As the original designer and leading manufacturer of LED retrofit kits in China, we have one of the most efficient LED Retrofit Kit available on the market today, and also have both USA and China’s Design & Utility Patents.

The 5th generation LED retrofit kits are upgraded to a more uniform and unique design with great performance enhancements. The Kits deliver over 125LPW. With best in class “Lumen per Watt Performance” one can expect maximized energy savings, it save up to 80% in electric, and eliminates your lighting maintenance for 10+ year by utilizing the highest quality LED chips, drivers, heat sinks, thermal pad, PCB boards, mounting arms, etc.

Specificaion Summary










 Power (W)
60W
60W
60W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
6,613
6,618
6,728


Efficacy (lm/W)
128
128
128


Input Voltage (V)
100-277V


Power Factor
>93%


THD
<12%


CRI
73


Beam Angle (°)
120°


 Installation
Horizontal / Vertical


Dimensions (in)
4.72"x 4.72"x1.97"


LED Class
Nichia, UL Listed: LM80


Driver Class
Meanwell, UL Listed: Class II


Controls
Dimming, Photocell, Motion sensor, Surge protection available


Operating Temperature
-35°C to 55°C


Certifications
ETL/cETL, LM79, LM80


L70 Lifetime (hours)
≥200,000 hours


Warranty
10-year limited on LED head, 5-year limited on driver









Features

• High output Nichia LEDs deliver up to 132 LPW
• Top brand Mean Well driver
• Upgraded unique and uniform modular design
• Light weight, more durable
• AL 6063 material of high structural intensity
• Unique and excellent thermal management ensures long life
• Over temperature protection system
• Various controls options meet any needs
• Adjustable and flexible brackets for retrofit a majority of fixtures
• Quick and easy installation
• Reduces energy and maintenance costs over 80%


Optics

• Beam angle: 120° standard




Warranty

• 10-year limited on LED head, 5-year limited on driver




Mountings

• Horizontal Installtion: Using "L " bracket
• Vertical Installation: Using "Flat Plates " bracket









Mass Production




Mountings

Application

Replaces existing metal halide and HPS lamps in street lights, wall packs, canopies, high bays and low bays fixtures, suitable for both vertical and horizontal installation
