Product Description
PRODUCT SPECIFICATIONS





Product name:

800w LED floodlights



Power:


800W




Working voltage:


AC90-305V, 50/60Hz




PF:


> 0.97




IP Grade:


IP65




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Light Efficiency:


100-110lm/w




View angle:


45°, 60°, 90°




CONFIGURATION




LED chip:


CREE XTE




LED driver:


Mean Well




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-30℃  to  50℃




Storage Temperature:


-30℃  to  60℃




Warranty:


5 Years




Certificates:


CE, RoHS, FCC





Product Dimension:



Application:

Best solution for golf court, football court, tennis court, stadium, dock, construction site, towers, building, skyscraper towers, etc.

Product Description
PRODUCT SPECIFICATIONS





Product name:

1000w LED flood lights



Power:


1000W




Working voltage:


AC90-305V, 50/60Hz




PF:


> 0.97




IP Grade:


IP65




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Light Efficiency:


100-110lm/w




View angle:


45°, 60°, 90°




CONFIGURATION




LED chip:


CREE XTE




LED driver:


Mean Well




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-30℃  to  50℃




Storage Temperature:


-30℃  to  60℃




Warranty:


5 Years




Certificates:


CE, RoHS, FCC





Product Dimension:



Application:

Best solution for golf court, football court, tennis court, stadium, dock, construction site, towers, building, skyscraper towers, etc.

Product Description



Product name:

DC24V solar LED flood lights 20W




Model No.:


SW-FL600-W20




Power:


20W




Working voltage:


AC100-240V, 50/60Hz; DC12V, or DC24V




PF:


> 0.95




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


20PCS Philips LED




LED driver:


CE approved IP67 rate




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC





Product Size:


Product Picture:



IES file and testing report are available for this model.

Product Description



Product name:

10 watts led floodlights




Power:


10W




Working voltage:


AC100-240V, 50/60Hz; DC12V, or DC24V




PF:


> 0.9




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


10PCS Philips LED




LED driver:


CE approved IP67 rate




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC





Dimension of this 10 watts LED floodlights:


Product Picture:


IES file and testing reports are available for this model.

Product Description
Product Name: 200w slim LED flood lights with SMD led




Product name:

200w Slim LED flood lights




Power:


200W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

110-120LM/W



CONFIGURATIONS




LED chip:


240PCS Philips LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC





Product Size:


Picture:

Product Description



Product name:

150w LED flood light with Pccooler radiator




Power:


150W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


150PCS Philips LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC





Product Size:


Picture:


150w outdoor led flood light are widely used for billboard lighting, garden decoration, building, shop, park, etc;

It is original Pccooler radiator, with IP65 design, waterproof, can be used in both outdoor areas and indoor areas.



Product Description



Product name:

100w Outdoor LED reflector floodlight




Power:


100W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


100PCS Philips LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC





Product Size:


Picture:


100w outdoor led reflector are widely used for billboard lighting, garden decoration, building, shop, park, etc;

It is original Pccooler radiator, with IP65 design, waterproof, can be used in both outdoor areas and indoor areas.

Product Description




Power:


80W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


80PCS Philips LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC







Product Size:


Picture:




80w LED floodlights are widely used for billboard lighting, garden decoration, building, shop, park, etc;

It is original Pccooler radiator, with IP65 design, waterproof, can be used in both outdoor areas and indoor areas.

Product Description




Power:


50W




Working voltage:


AC100-240V, 50/60Hz; DC12V, or DC24V




PF:


> 0.95




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


50PCS Philips LED




LED driver:


CE approved IP67 rate




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC





Product Size
:

Picture:


50w LED reflector are widely used for billboard lighting, garden decoration, building, shop, park, etc;

It is IP65 design, waterproof, can be used in both outdoor areas and indoor areas.

Product Description




Power:


30W




Working voltage:


AC100-240V, 50/60Hz; DC12V, or DC24V




PF:


> 0.95




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

100-110LM/W



CONFIGURATIONS




LED chip:


30PCS Philips LED




LED driver:


CE approved IP67 rate




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


3 Years, or 5 Years




Certificates:


CE, RoHS, FCC






Product Size:



Picture:



IES file and testing report are available for this model.

Product Description

Product Feature:

●High quality light source, high lumen, long life of light source

●Aviation aluminum lamp body, fine aluminum casting, by baking paint treatment,with oxidation resistance, flame retardant, not easy to change color.

●Air convection heat dissipation, integrated thickened aluminum + convection design, to solve the heat dissipation problem, ensure the life of the light source.

●High quality tempered glass cover, high light transmittance, uniform light color.

●Bracket is adjustable for different installation angle.

●IP65 waterproof fit to wet location.



Product Specification:




Watt
100W


Total Lumens
13000LM


Dimension
295*350*63mm


Beam Angle
120°


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
UL / DLC / CE / RoHS


Warranty Time
5  Years








Product Display:





Product Details:











Product Dimension:





Application:

Widely used in building facades, plaza, garden landscape, golf courses, villas, parks, farms and other outdoor places.

Product Description

Product Feature:

●High quality light source, high lumen, long life of light source

●Aviation aluminum lamp body, fine aluminum casting, by baking paint treatment,with oxidation resistance, flame retardant, not easy to change color.

●Air convection heat dissipation, integrated thickened aluminum + convection design, to solve the heat dissipation problem, ensure the life of the light source.

●High quality tempered glass cover, high light transmittance, uniform light color.

●Bracket is adjustable for different installation angle.

●IP65 waterproof fit to wet location.



Product Specification:




Watt
150W
200W


Total Lumens
19500LM
62000LM


Dimension
320*400*76mm


Beam Angle
120°


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
UL / DLC / CE / RoHS


Warranty Time
5  Years






Product Display:





Product Details:









Product Dimension:





Application:

Widely used in building facades, plaza, garden landscape, golf courses, villas, parks, farms and other outdoor places.
