Model No：KWEBU-ST-01

KAIWIM LED Street Light is an ideal replacement for HID/ metal halide and reduces wattages as much as 75%. With over 130 LPW, this product is well suited for many applications: roadways, industrial parking lots, residential areas, sidewalks, walkways, etc. Reduce energy and maintenance costs, while improving the appearance of any outdoor environment.

KAIWIM LED LED Street Light is designed to offer better security, more lumens, and higher cost savings. Using up to 70% less power over traditional metal halide or high pressure sodium lighting. This product is optimal for retrofit installations or new construction installations.

KAIWIM LED Street Light is perfect replacement for traditional lights, it can save up to 80% electricity cost, better efficiency, longer lifespan. It is IP66 waterproof rating for roadway
lighting with good water and weather resistance. Come with optically optimized PC lenses, uniformity in light distribution.

50W~300W KAIWIM LED Street Light is designed to offer better security, more lumens, and higher cost savings. Using up to 70% less power over traditional metal halide or high pressure sodium lighting. This product is optimal for retrofit installations or new construction installations.

KAIWIN LED street light offers from 30-watt to the 150-watt, built using the ergonomically designed body to enhance the heat dissipation for the CREE 3030 chip which will deliver an impressive 130 Lumens Per Watt. This street light lamp is available in 1-10v Dimming, microwave motion sensor, photocell sensor functions.

Product Description

Product Feature:

·Use high bright CREE 3030, the luminous efficiency of whole lamp up to 130lm/W.

·IP65 rated for wet location.

·Photocell sensor and dimmable function for option.

·3 kinds of mounting methods are available for different installation.

·Offering 5 years warranty, over 50,000 hours lifetime.

·Modular design allows for separation of components for best heat dissipation.

·Die-cast and powder coated aluminium housing for better anti-corrosion.

·ETL/DLC/CE/RoHS/LM79/LM80/IES for quality assurance and safe operation.



Product Specification:




Watt
60W
100W
150W


Total Lumens
7800LM
13000LM
19500LM


Dimension
495*310*84mm


Beam Angle
TYPE3,TYPE4,TYPE5


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
ETL / cETL/ DLC/ CE / RoHS


Warranty Time
5  Years






Product Details:





4 Kinds Of Mounting Methods:





Light Distribution Curve [Unit:cd]



Application:

Widely used for Parking Lot Lighting, Square Lighting, Roadway Lighting, Outdoor Area Lighting, High Mast Lighting, Area Lighting.

Product Description

Product Feature:

·Use high bright CREE 3030, the luminous efficiency of whole lamp up to 130lm/W.

·IP65 rated for wet location.

·Photocell sensor and dimmable function for option.

·3 kinds of mounting methods are available for different installation.

·Offering 5 years warranty, over 50,000 hours lifetime.

·Modular design allows for separation of components for best heat dissipation.

·Die-cast and powder coated aluminium housing for better anti-corrosion.

·ETL/DLC/CE/RoHS/LM79/LM80/IES for quality assurance and safe operation.



Product Specification:




Watt
60W
100W
150W


Total Lumens
7800LM
13000LM
19500LM


Dimension
495*310*84mm


Beam Angle
TYPE3,TYPE4,TYPE5


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
ETL / cETL/ DLC/ CE / RoHS


Warranty Time
5  Years






Product Details:





4 Kinds Of Mounting Methods:





Light Distribution Curve [Unit:cd]



Application:

Widely used for Parking Lot Lighting, Square Lighting, Roadway Lighting, Outdoor Area Lighting, High Mast Lighting, Area Lighting.





Product Description

Product Feature:

● Suitable to diameter 60mm/80mm pole.

● CREE LED 130lm/w high brightness.

● Dusk to dawn Photocell function available.

● Dimmable available.

● IP65 waterproof rating for wet and damp location.

● Quiet operation, no audible hum or noise.

● Working environment in -30℃to 50℃.

● DLC/ETL/CE/ROHS/LM79/LM80 for quality assurance and safety operation.

● IES files are available.

● 5 years warranty.



Product Specification:




Watt
60W


Total Lumens
7800LM


Beam Angle
120°/ 140°


Dimension
Φ360* H520mm


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
ETL/cETL /DLC / CE / RoHS


Warranty Time
5  Years






Product Display:



Product Details:



Product Dimension:





Application:

Garage, parking lot, square, alley, back street, garden, yard etc.





Product Description

Product Feature:

● Suitable to diameter 60mm/80mm pole.

● CREE LED 130lm/w high brightness.

● Dusk to dawn Photocell function available.

● Dimmable available.

● IP65 waterproof rating for wet and damp location.

● Quiet operation, no audible hum or noise.

● Working environment in -30℃to 50℃.

● DLC/ETL/CE/ROHS/LM79/LM80 for quality assurance and safety operation.

● IES files are available.

● 5 years warranty.



Product Specification:




Watt
100W


Total Lumens
13000LM


Beam Angle
120°/ 140°


Dimension
Φ360* H520mm


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
ETL/cETL /DLC / CE / RoHS


Warranty Time
5  Years






Product Display:



Product Details:



Product Dimension:





Application:

Garage, parking lot, square, alley, back street, garden, yard etc.





Product Description

Product Feature:

● Suitable to diameter 60mm/80mm pole.

● CREE LED 130lm/w high brightness.

● Dusk to dawn Photocell function available.

● Dimmable available.

● IP65 waterproof rating for wet and damp location.

● Quiet operation, no audible hum or noise.

● Working environment in -30℃to 50℃.

● DLC/ETL/CE/ROHS/LM79/LM80 for quality assurance and safety operation.

● IES files are available.

● 5 years warranty.



Product Specification:




Watt
150W


Total Lumens
19500LM


Beam Angle
120°/ 140°


Dimension
Φ360* H520mm


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
ETL/cETL /DLC / CE / RoHS


Warranty Time
5  Years






Product Display:



Product Details:



Product Dimension:





Application:

Garage, parking lot, square, alley, back street, garden, yard etc.





Product Description

Product Feature:

●High quality light source, high lumen, long life of light source

●Aviation aluminum lamp body, fine aluminum casting, by baking paint treatment,with oxidation resistance, flame retardant, not easy to change color.

●Air convection heat dissipation, integrated thickened aluminum + convection design, to solve the heat dissipation problem, ensure the life of the light source.

●High quality tempered glass cover, high light transmittance, uniform light color.

●Bracket is adjustable for different installation angle.

●IP65 waterproof fit to wet location.



Product Specification:




Watt
100W


Total Lumens
13000LM


Dimension
295*350*63mm


Beam Angle
120°


CCT
3000K-6000K


Input Voltage
AC100-277V, 50-60Hz


CRI
>80


Power Factor
>0.9


Operating Temperature
-35℃~55℃


IP Rating
IP65


Test Standard
IES/LM79/LM80


Safety Certification
UL / DLC / CE / RoHS


Warranty Time
5  Years








Product Display:





Product Details:











Product Dimension:





Application:

Widely used in building facades, plaza, garden landscape, golf courses, villas, parks, farms and other outdoor places.
