Product Description

KAIWIM LED wall pack is designed to replace metal halide/high pressure solid wall pack. It can replace 50W-400W metal halide wall pack with lighting efficacy up to 139lm/w, over 75% energy saving.
Constructed with high quality thermal heat sink, features excellent heat dissipation, LED TC<75°C(25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
The housing is designed to be mounted on junction boxes or direct wall mounts with feed through conduit access for easy installation.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, emergency back-up, etc.
LED Wall Pack series is IP65 rated, suitable for damp and wet locations, the fixture is ideal for outdoor walkways, entry ways, pathways, landscapes, public areas, security lighting, etc.


Specification Summary










 Power (W)
40W
40W
40W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
5,234
5,234
5,234


Efficacy (lm/W)
131
131
131


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Optics
UV Resistant High Quality PC Lens


Beam Angle (°)
70°x110°


Dimensions (in)
13.1''(L) x 9.5''(W) x 7.5'' (H)


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Sensors, Emergency battery back-up available


Environment
Outdoor & Indoor Applications


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 139 LPW
• Class II UL listed driver
• Die-casting Aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Sealed to be dirt and bug proof
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 75%




Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Surge protector (over current device) optional



Installation

• Wall mount, can mount to recessed outlet boxes
or directly to surfaces




Housing & Finish

• Die-casting Aluminum heat sink
• UV resistant high quality Lens(Std.)
• Tempered and shatter-resistant glass optional
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Standard
• ETL/cETL listed (14W, 22W)
• UL/cUL listed (40W, 60W, 80W, 100W)
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• 100°x 85° for Mini Wall Pack
• 70°x 110° for Forward Throw Wall Pack


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.











High Quality Nichia LED Chips

1.Top brand high quality Nichia chips (L90>50,000hrs).
2.Super high light efficacy.
3.EnGreen Inovaneered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




UV resistant high quality PC lens

1. Patent unique design.
2. Meet DLC Premium 4.0 lighting requirment, NO need extra cover or shield.
3. Light-weight than traditional glass cover.
4.Shatterproof.
5. Btter waterproof performance.
6. UV resistant, NO NEED TO WORRY DISCOLOR.






Various Options

1. Available with 0-10v Dimmable driver.
2. For Medium /Large WP: Photocell, Motion sensor &
Remote controller, dimming driver, Emergency battery back
up unit etc.
3. 100-277V and 347-480V available.
4. Our Patent unique design.
5. Better heat dissipation, no need addtional heat sink.
6. Conduit entrances on back, side and bottom.






Dimension











Applications

• Area Lighting
• Security Lighting
• Building Accent Lighting

The 4WP series is IP65 rated, suitable for damp and wet locations,
the fixture is ideal for outdoor walkways, entry ways, pathways,
landscapes, public areas, security lighting, etc.


Projects that feedback from our customers

Location: Westmon IL, USA

Product: 60W LED wall pack light 98 units

Product Description

KAIWIM LED wall pack is designed to replace metal halide/high pressure solid wall pack. It can replace 50W-400W metal halide wall pack with lighting efficacy up to 139lm/w, over 75% energy saving.
Constructed with high quality thermal heat sink, features excellent heat dissipation, LED TC<75°C(25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
The housing is designed to be mounted on junction boxes or direct wall mounts with feed through conduit access for easy installation.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, emergency back-up, etc.
LED Wall Pack series is IP65 rated, suitable for damp and wet locations, the fixture is ideal for outdoor walkways, entry ways, pathways, landscapes, public areas, security lighting, etc.


Specification Summary










 Power (W)
60W
60W
60W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
7,928
7,928
7,928


Efficacy (lm/W)
132
132
132


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Optics
UV Resistant High Quality PC Lens


Beam Angle (°)
70°x110°


Dimensions (in)
13.1''(L) x 9.5''(W) x 7.5''(H)


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Sensors, Emergency battery back-up available


Environment
Outdoor & Indoor Applications


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 139 LPW
• Class II UL listed driver
• Die-casting Aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Sealed to be dirt and bug proof
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 75%




Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Surge protector (over current device) optional



Installation

• Wall mount, can mount to recessed outlet boxes
or directly to surfaces




Housing & Finish

• Die-casting Aluminum heat sink
• UV resistant high quality Lens(Std.)
• Tempered and shatter-resistant glass optional
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Standard
• ETL/cETL listed (14W, 22W)
• UL/cUL listed (40W, 60W, 80W, 100W)
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• 100°x 85° for Mini Wall Pack
• 70°x 110° for Forward Throw Wall Pack


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.











High Quality Nichia LED Chips

1.Top brand high quality Nichia chips (L90>50,000hrs).
2.Super high light efficacy.
3.EnGreen Inovaneered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




UV resistant high quality PC lens

1. Patent unique design.
2. Meet DLC Premium 4.0 lighting requirment, NO need extra cover or shield.
3. Light-weight than traditional glass cover.
4.Shatterproof.
5. Btter waterproof performance.
6. UV resistant, NO NEED TO WORRY DISCOLOR.






Various Options

1. Available with 0-10v Dimmable driver.
2. For Medium /Large WP: Photocell, Motion sensor &
Remote controller, dimming driver, Emergency battery back
up unit etc.
3. 100-277V and 347-480V available.
4. Our Patent unique design.
5. Better heat dissipation, no need addtional heat sink.
6. Conduit entrances on back, side and bottom.






Dimension











Applications

• Area Lighting
• Security Lighting
• Building Accent Lighting

The 4WP series is IP65 rated, suitable for damp and wet locations,
the fixture is ideal for outdoor walkways, entry ways, pathways,
landscapes, public areas, security lighting, etc.


Projects that feedback from our customers

Location: Westmon IL, USA

Product: 60W LED wall pack light 98 units

Product Description

KAIWIM LED wall pack is designed to replace metal halide/high pressure solid wall pack. It can replace 50W-400W metal halide wall pack with lighting efficacy up to 139lm/w, over 75% energy saving.
Constructed with high quality thermal heat sink, features excellent heat dissipation, LED TC<75°C(25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
The housing is designed to be mounted on junction boxes or direct wall mounts with feed through conduit access for easy installation.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, emergency back-up, etc.
LED Wall Pack series is IP65 rated, suitable for damp and wet locations, the fixture is ideal for outdoor walkways, entry ways, pathways, landscapes, public areas, security lighting, etc.

Specification Summary










 Power (W)
80W
80W
80W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
11,065
11,065
11,065


Efficacy (lm/W)
138
138
138


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Optics
UV Resistant High Quality PC Lens


Beam Angle (°)
70°x110°


Dimensions (in)
18.5''(L) x 9.5''(W) x 9''(H)


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Sensors, Emergency battery back-up available


Environment
Outdoor & Indoor Applications


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 139 LPW
• Class II UL listed driver
• Die-casting Aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Sealed to be dirt and bug proof
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 75%




Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Surge protector (over current device) optional



Installation

• Wall mount, can mount to recessed outlet boxes
or directly to surfaces




Housing & Finish

• Die-casting Aluminum heat sink
• UV resistant high quality Lens(Std.)
• Tempered and shatter-resistant glass optional
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Standard
• ETL/cETL listed (14W, 22W)
• UL/cUL listed (40W, 60W, 80W, 100W)
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• 100°x 85° for Mini Wall Pack
• 70°x 110° for Forward Throw Wall Pack


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.











High Quality Nichia LED Chips

1.Top brand high quality Nichia chips (L90>50,000hrs).
2.Super high light efficacy.
3.EnGreen Inovaneered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




UV resistant high quality PC lens

1. Patent unique design.
2. Meet DLC Premium 4.0 lighting requirment, NO need extra cover or shield.
3. Light-weight than traditional glass cover.
4.Shatterproof.
5. Btter waterproof performance.
6. UV resistant, NO NEED TO WORRY DISCOLOR.






Various Options

1. Available with 0-10v Dimmable driver.
2. For Medium /Large WP: Photocell, Motion sensor &
Remote controller, dimming driver, Emergency battery back
up unit etc.
3. 100-277V and 347-480V available.
4. Our Patent unique design.
5. Better heat dissipation, no need addtional heat sink.
6. Conduit entrances on back, side and bottom.






Dimension











Applications

• Area Lighting
• Security Lighting
• Building Accent Lighting

The 4WP series is IP65 rated, suitable for damp and wet locations,
the fixture is ideal for outdoor walkways, entry ways, pathways,
landscapes, public areas, security lighting, etc.


Projects that feedback from our customers

Location: Westmon IL, USA

Product: 60W LED wall pack light 98 units

Product Description

KAIWIM LED wall pack is designed to replace metal halide/high pressure solid wall pack. It can replace 50W-400W metal halide wall pack with lighting efficacy up to 139lm/w, over 75% energy saving.
Constructed with high quality thermal heat sink, features excellent heat dissipation, LED TC<75°C(25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
The housing is designed to be mounted on junction boxes or direct wall mounts with feed through conduit access for easy installation.
In addition, this fixture offers multiple options to meet any need-e.g. electric controls, optics, emergency back-up, etc.
LED Wall Packseries is IP65 rated, suitable for damp and wet locations, the fixture is ideal for outdoor walkways, entry ways, pathways, landscapes, public areas, security lighting, etc.

Specification Summary










 Power (W)
100W
100W
40W


Color Temperature (CCT)
4000K
4500K
5000K


Lumen Output (LM)
13,695
13,695
13,695


Efficacy (lm/W)
140
140
140


Input Voltage (V)
100-277V


Power Factor
>90%


THD
<20%


CRI
73


Optics
UV Resistant High Quality PC Lens


Beam Angle (°)
70°x110°


Dimensions (in)
18.5''(L) x 9.5''(W) x 9''(H)


LED Class
UL Listed: LM80


Driver Class
UL Listed: Class II


Controls
Dimming, Sensors, Emergency battery back-up available


Environment
Outdoor & Indoor Applications


Operating Temperature
–25°C to +45°C


Certifications
UL/cUL, LM79, LM80


L70 Lifetime (hours)
150,000 hours per L70 TM-21@ 25°C


Warranty
6-year limited system warranty standard









Features

• High system efficacy up to 139 LPW
• Class II UL listed driver
• Die-casting Aluminum heat sink, LED TC<75°C(25°C ambient)
• Excellent thermal management ensures long lifespan
• UV resistant high quality lens
• Sealed to be dirt and bug proof
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 75%




Controls
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Surge protector (over current device) optional



Installation

• Wall mount, can mount to recessed outlet boxes
or directly to surfaces




Housing & Finish

• Die-casting Aluminum heat sink
• UV resistant high quality Lens(Std.)
• Tempered and shatter-resistant glass optional
• Bronze finish standard, black and white optional
• RAL & custom colors available


Compliance

• DLC Standard
• ETL/cETL listed (14W, 22W)
• UL/cUL listed (40W, 60W, 80W, 100W)
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available




Optics

• 100°x 85° for Mini Wall Pack
• 70°x 110° for Forward Throw Wall Pack


Ratings

• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C




Electrical

• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming and 0-10V dimming


Warranty

• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.











High Quality Nichia LED Chips

1.Top brand high quality Nichia chips (L90>50,000hrs).
2.Super high light efficacy.
3.EnGreen Inovaneered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.




UV resistant high quality PC lens

1. Patent unique design.
2. Meet DLC Premium 4.0 lighting requirment, NO need extra cover or shield.
3. Light-weight than traditional glass cover.
4.Shatterproof.
5. Btter waterproof performance.
6. UV resistant, NO NEED TO WORRY DISCOLOR.






Various Options

1. Available with 0-10v Dimmable driver.
2. For Medium /Large WP: Photocell, Motion sensor &
Remote controller, dimming driver, Emergency battery back
up unit etc.
3. 100-277V and 347-480V available.
4. Our Patent unique design.
5. Better heat dissipation, no need addtional heat sink.
6. Conduit entrances on back, side and bottom.






Dimension











Applications

• Area Lighting
• Security Lighting
• Building Accent Lighting

The 4WP series is IP65 rated, suitable for damp and wet locations,
the fixture is ideal for outdoor walkways, entry ways, pathways,
landscapes, public areas, security lighting, etc.


Projects that feedback from our customers

Location: Westmon IL, USA

Product: 60W LED wall pack light 98 units

Product Description
Specifications:





Product name:


150w LED street lighting




Power:


150W




Working voltage:


AC90-305V, 50/60Hz; AC180-277V




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

160LM/W



CONFIGURATIONS




LED chip:


Well-known brand 5050 SMD led




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black, Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Net Weight:

8.0 KGS



Gross Weight:

9.8 KGS



Packing Size:

64*36*20CM



Warranty:


5 Years




Certificates:


CE, RoHS, FCC, SAA, ETL, DLC








Application

Widely used in arterial roads,highways,elevated road,city streets,bridges,sidewalks road lighting,and the square,schools,residential areas,industrial ares,parks and other outdoor lighting places need.

Product Description
Specifications:





Product name:


160lm/w 200w LED street lighting




Power:


200W




Working voltage:


AC90-305V, 50/60Hz; AC180-277V




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

160LM/W



CONFIGURATIONS




LED chip:


Well-known brand 5050 SMD led




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black, Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Net Weight:

9.0 KGS



Gross Weight:

10.5 KGS



Packing Size:

73*36*20CM



Warranty:


5 Years




Certificates:


CE, RoHS, FCC, SAA, ETL, DLC








Application

Widely used in arterial roads,highways,elevated road,city streets,bridges,sidewalks road lighting,and the square,schools,residential areas,industrial ares,parks and other outdoor lighting places need.

Product Description
Specifications:





Product name:


160lm/w 240w LED street lighting




Power:


240W




Working voltage:


AC90-305V, 50/60Hz; AC180-277V




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

160LM/W



CONFIGURATIONS




LED chip:


Well-known brand 5050 SMD led




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black, Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Net Weight:

10.5 KGS



Gross Weight:

12.5 KGS



Packing Size:

82*36*20CM



Warranty:


5 Years




Certificates:


CE, RoHS, FCC, SAA, ETL, DLC







Application

Widely used in arterial roads,highways,elevated road,city streets,bridges,sidewalks road lighting,and the square,schools,residential areas,industrial ares,parks and other outdoor lighting places need.

Product Description
Specifications:





Product name:


160lm/w 300w LED street lighting




Power:


300W




Working voltage:


AC90-305V, 50/60Hz; AC180-277V




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-4500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

160LM/W



CONFIGURATIONS




LED chip:


Well-known brand 5050 SMD led




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black, Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Net Weight:

12.00 KGS



Gross Weight:

14.00 KGS



Packing Size:

91*36*20CM



Warranty:


5 Years




Certificates:


CE, RoHS, FCC, SAA, ETL, DLC








Application

Widely used in arterial roads,highways,elevated road,city streets,bridges,sidewalks road lighting,and the square,schools,residential areas,industrial ares,parks and other outdoor lighting places need.

Product Description
Product Name: 35w led street lamps with photocell

Using LumiLEDs super bright 3030 smd(P or Q bin only)





Power:


35W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-5500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

130-140LM/W



CONFIGURATIONS




LED chip:


72pcs LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


TUV, SAA, C-TICK, CE, RoHS







Product Applications

Widely used in city street, municipal roadways, highway, bridges, housing project, public parks, parking lots, yards and gardens ect.

Product Description
Product Name: 50w led street lamps with photocell

Using LumiLEDs super bright 3030 smd(P or Q bin only)





Power:


50W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-5500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

130-140LM/W



CONFIGURATIONS




LED chip:


72pcs LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


TUV, SAA, C-TICK, CE, RoHS







Product Applications

Widely used in city street, municipal roadways, highway, bridges, housing project, public parks, parking lots, yards and gardens ect.

Product Description
Product Name: 80w led street lamps with photocell

Using LumiLEDs super bright 3030 smd(P or Q bin only)





Power:


80W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-5500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

120-130LM/W



CONFIGURATIONS




LED chip:


96pcs LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


TUV, SAA, C-TICK, CE, RoHS








Product Applications

Widely used in city street, municipal roadways, highway, bridges, housing project, public parks, parking lots, yards and gardens ect.

Product Description
Product Name: 100w LED street lamps with Photocell

Using LumiLEDs super bright 3030 smd(P or Q bin only)





Power:


100W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-5500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

130-140LM/W



CONFIGURATIONS




LED chip:


180pcs LED




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Grey




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


TUV, SAA, C-TICK, CE, RoHS







Product Applications

Widely used in city street, municipal roadways, highway, bridges, housing project, public parks, parking lots, yards and gardens ect.
