Feature / Warranty





The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space


IP rate





Aluminum Profiles





   1616







       1708







             2308






Electrical & Output Data



Step length (mm/x LED)：100mm/3LEDs
Number LED/m：30
Voltage (v)：12 V
Ra：NA
Beam Angle(º)：120
Power (w/m)：7.2
FPC width (mm)：10
Max. length per circuit (m)：5
IP rate：20/65/66/67/68
Installation：3M Tape / Mounting Clips / Aluminum Profiles





Dimensions & available lengths



Illuminance Distribution






Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space

IP rate


Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
14.4
19.2


FPC width (mm)
12
12


Max. length per circuit (m)
5
5


IP rate
20/65
20/65


Installation
3M Tape / Mounting Clips / Aluminum Profiles






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate


Aluminum Profiles




Electrical & Output Data



Step length (mm/x LED)：100mm/18LEDs
Number LED/m：180
Voltage (v)：24 V
Ra：80
Beam Angle(º)：120
Power (w/m)：19.2
FPC width (mm)：12
Max. length per circuit (m)：5
IP rate：20/65
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate



Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
17.2
17.2


FPC width (mm)
12
12


Max. length per circuit (m)
5
5


IP rate
20/65
20/65


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate


Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
17.2
17.2


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65
20/65


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate


Aluminum Profiles



Electrical & Output Data



Step length (mm/x LED)：62.5mm/6LEDs
Number LED/m：96
Voltage (v)：24 V
Ra：NA
Beam Angle(º)：120
Power (w/m)：18.43
FPC width (mm)：10
Max. length per circuit (m)：5
IP rate：20/65
Installation：3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output



Illuminance Distribution

Feature / Warranty





The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space


IP rate





Aluminum Profiles





   1616







       1708







             2308





Electrical & Output Data







Step length (mm/x LED)
100mm/6LEDs
166.6mm/10LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
11.52
13.8


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty





The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space


IP rate





Aluminum Profiles





   1616







       1708







             2308





Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
NA
NA


Beam Angle(º)
120
120


Power (w/m)
11.52
11.52


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space




IP rate





Aluminum Profiles





   1616







       1708







           2308




Electrical & Output Data






Step length (mm/x LED)
25mm/3LEDs
166.6mm/5LEDs


Number LED/m
30
30


Voltage (v)
12V
24V


Ra
NA
NA


Beam Angle(º)
120
120


Power (w/m)
5.76
6.9


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles











Dimensions & available lengths






Illuminance Distribution

Feature / Warranty







The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space



IP rate




Aluminum Profiles





     1616







         1708







            230






Electrical & Output Data





Step length (mm/x LED)
100mm / 3LEDs
166.6mm / 6LEDs


Number LED/m
30
60


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
11.52
11.52


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Pro?les





Light efficiency & Lumen Output





Luminaireeficacy (3000K)
95lm/W@Ra80
79.8lm/W@Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 947lm
 809lm


2500K
 985lm
 827lm


2700K
 1040lm
 905lm


3000K
 1094lm
 919lm


3500K
 1094lm
 938lm


4000K
 1094lm
 992lm


5000K
 1094lm
 967lm


6000K
 1058lm
 967lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space




IP rate







Aluminum Profiles






   1616







        1708







           2308





Electrical & Output Data





Step length (mm/x LED)
100mm / 3LEDs
166.6mm / 5LEDs


Number LED/m
30
30


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
5.76
6.9


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Pro?les





Light efficiency & Lumen Output





Luminaireeficacy (3000K)
95lm/W@Ra80
79.8lm/W@Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 471lm
 404lm


2500K
 492lm
 414lm


2700K
 520lm
 453lm


3000K
 547lm
 460lm


3500K
 547lm
 469lm


4000K
 547lm
 496lm


5000K
 547lm
 484lm


6000K
 529lm
 484lm





Dimensions & available lengths



Illuminance Distribution
