2835 LED Strips

  • Read More

    150lm/W SMD2835-80-8mm-5m

    Feature / Warranty







    ◆ We selected DC2.8-2.9V, 27-29LM, SMD2835 chips and adopted DC24V and 8 leds/group
    solution to design 150LM/W Led Strips.
    ◆ Sometimes customer want high brightness but compliant heat dissipation problem,
    150LM/W led strips could be a better choice.
    ◆ Adopt 1:2 OZ RA Copper PCB to reduce the voltage drop.
    ◆ We found that SMD2835 chips could get highest light efficiency when the drive current is 30ma.


    IP rate




    Aluminum Profiles






        1616

    Electrical & Output Data



    Step length (mm/x LED):100mm/8LEDs
    Number LED/m:80
    Voltage (v):24V
    Ra:80 / 90
    Beam Angle(º):120
    Power (w/m):7.2
    FPC width (mm):8
    Max. length per circuit (m):5
    IP rate:20/65/66/67/68
    Installation3M:Tape / Mounting Clips / Aluminum Profiles



    Light efficiency & Lumen Output





    Luminaire efficacy (3000K)
    150lm/W @Ra80
    130lm/W @Ra90


    LED color
    Ra80
    Ra90


     = Popular Color
     = Niche Color


    2300K
     886lm
     768lm


    2500K
     929lm
     805lm


    2700K
     942lm
     842lm


    3000K
     1004lm
     870lm


    3500K
     1026lm
     889lm


    4000K
     1080lm
     836lm


    5000K
     1080lm
     936lm


    6000K
     1048lm
     908lm











             1708







                2308
  • Read More

    1900K 2835 strips – strips-Design for Special Meat

    Feature / Warranty



    Quality meat products and fresh poultry products must look clean and health.
    The faint pink color makes the beef and mutton (red meat) look fresher and more attractive.


    IP rate



    Electrical & Output Data





    Voltage
    DC12V/24V
    DC24V
    DC24V
    DC24V


    CCT
    1900k
    1900k
    1900k
    1900k


    Number LED/m
    120
    128
    160
    224


    Lumen/m
    677lm
    1060lm
    1325lm
    1423lm


    Luminaire efficacy
    53lm/w
    69lm/w
    69lm/w
    71lm/w


    Power (w/m)
    12.8 W
    15.36 W
    19.2W
    20.16 W


    Max. length per circuit
    4m
    4m
    4m
    4m


    FPC width
    10mm/6LEDs/50mm
    10mm
    10mm
    10mm


    Step length
    3LEDs/25mm
    8LEDs/62.5mm
    8LEDs/50mm
    8LEDs/35.7mm


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Optimal Lllumination Map



  • Read More

    2500K 2835 strips – strips-Design for golden bread

    Feature / Warranty



    Warm-colored lighting makes golden baked goods look more delicious and attractive, giving a freshly baked feel.


    IP rate





    Electrical & Output Data





    Voltage
    DC12V/24V
    DC24V
    DC24V
    DC24V


    CCT
    2500K
    2500K
    2500K
    2500K


    Number LED/m
    120
    128
    160
    224


    Lumen/m
    1147lm
    1775lm
    2220lm
    2370lm


    Luminaire efficacy
    90lm/w
    116lm/w
    116lm/w
    118lm/w


    Power (w/m)
    12.8 W
    15.36 W
    19.2W
    20.16 W


    Max. length per circuit
    4m
    4m
    4m
    4m


    FPC width
    10mm/6LEDs/50mm
    10mm
    10mm
    10mm


    Step length
    3LEDs/25mm
    8LEDs/62.5mm
    8LEDs/50mm
    8LEDs/35.7mm


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Optimal Lllumination Map









  • Read More

    3100K 2835 strips – strips-Design for Fresh Meat

    Feature / Warranty



    Quality meat products and fresh poultry products must look clean and health.
    The faint pink color makes the beef and mutton (red meat) look fresher and more attractive.


    IP rate



    Electrical & Output Data





    Voltage
    DC12V/24V
    DC24V
    DC24V
    DC24V


    CCT
    3100K
    3100K
    3100K
    3100K


    Number LED/m
    120
    128
    160
    224


    Lumen/m
    708lm
    1109lm
    1386lm
    1488lm


    Luminaire efficacy
    55lm/w
    72lm/w
    72lm/w
    74lm/w


    Power (w/m)
    12.8 W
    15.36 W
    19.2W
    20.16 W


    Max. length per circuit
    4m
    4m
    4m
    4m


    FPC width
    10mm/6LEDs/50mm
    10mm
    10mm
    10mm


    Step length
    3LEDs/25mm
    8LEDs/62.5mm
    8LEDs/50mm
    8LEDs/35.7mm


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Optimal Lllumination Map



  • Read More

    4020K 2835 strips – Design for Fish & Seafood

    Feature / Warranty



    ◆White light with a strong contrast effect allows seafood products to shine in glittering crushed ice, make the seafood more fresh.
    ◆This lighting solution is equally suitable for sushi and sashimi.

    IP rate




    Electrical & Output Data





    Voltage
    DC12V/24V
    DC24V
    DC24V
    DC24V


    CCT
    4020K
    4020K
    4020K
    4020K


    Number LED/m
    120
    128
    160
    224


    Lumen/m
    895lm
    895lm
    1766lm
    189lm


    Luminaire efficacy
    70 lm/w
    92lm/w
    72lm/w
    94 lm/w


    Power (w/m)
    12.8 W
    15.36 W
    19.2W
    20.16 W


    Max. length per circuit
    4m
    4m
    4m
    4m


    FPC width
    10mm/6LEDs/50mm
    10mm
    10mm
    10mm


    Step length
    3LEDs/25mm
    8LEDs/62.5mm
    8LEDs/50mm
    8LEDs/35.7mm


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Optimal Lllumination Map



  • Read More

    5000K 2835 strips – for Fruits and vegetables

    Feature / Warranty



    The most suitable color for fruits and vegetables are soft pure white, and the original colors of these products can be truly reflected under the light.
    Some vegetables are also very sensitive to heat and glare, so LED light sources that are bright and do not generate too much heat are the best choice.
    This lighting solution is equally suitable for flowers.


    IP rate




    Electrical & Output Data





    Voltage
    DC12V/24V
    DC24V
    DC24V
    DC24V


    CCT
    5000K
    5000K
    5000K
    5000K


    Number LED/m
    120
    128
    160
    224


    Lumen/m
    895lm
    1659lm
    2074lm
    2225lm


    Luminaire efficacy
    70 lm/w
    108lm/w
    72 lm/w
    110lm/w


    Power (w/m)
    12.8 W
    15.36 W
    19.2W
    20.16 W


    Max. length per circuit
    4m
    4m
    4m
    4m


    FPC width
    10mm/6LEDs/50mm
    10mm
    10mm
    10mm


    Step length
    3LEDs/25mm
    8LEDs/62.5mm
    8LEDs/50mm
    8LEDs/35.7mm


    Installation
    3M Tape / Mounting Clips / Aluminum Profiles





    Optimal Lllumination Map
