Feature / Warranty



◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.


IP rate




Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80 / 90 / 95
80 / 90 / 95


Beam Angle(º)
120
120


Power (w/m)
11.5
11.52


FPC width (mm)
8
8


Max. length per circuit (m)
5
5


IP rate
20
20


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
90lm/W @Ra80
74.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
912m
 757lm


2500K
 954lm
 783lm


2700K
 995lm
 818lm


3000K
 1037lm
 861lm


3500K
 1058lm
 878m


4000K
 1114lm
 924lm


5000K
 1078lm
 921lm


6000K
 1078lm
 921lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.

IP rate




Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
71.4mm/7LEDs



Number LED/m
196



Voltage (v)
24V



Ra
80 / 90 / 95



Beam Angle(º)
120



Power (w/m)
20



FPC width (mm)
15



Max. length per circuit (m)
5



IP rate
20



Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
114lm/W @Ra80
94.6lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
2006lm
 1665lm


2500K
 2098lm
 1722lm


2700K
 2189lm
 1789lm


3000K
 2280lm
 1892lm


3500K
 2326lm
 1930lm


4000K
 1450lm
 2032lm


5000K
 2371lm
 2025lm


6000K
 2371lm
 2025lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.


IP rate




Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
38.5mm/7LEDs



Number LED/m
182



Voltage (v)
24V



Ra
80 / 90 / 95



Beam Angle(º)
120



Power (w/m)
15



FPC width (mm)
10



Max. length per circuit (m)
5



IP rate
20/65



Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
115lm/W @Ra80
95.5lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
1518lm
 1260lm


2500K
 1587lm
 1303lm


2700K
 1656lm
 1360lm


3000K
 1725lm
 1432lm


3500K
 1760lm
 1537lm


4000K
 1854lm
 1537lm


5000K
 1794lm
 1532lm


6000K
 1794lm
 1532lm





Dimensions & available lengths



Illuminance Distribution




Feature / Warranty



◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.


IP rate




Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/7LEDs



Number LED/m
140



Voltage (v)
24V



Ra
80 / 90 / 95



Beam Angle(º)
120



Power (w/m)
14.4



FPC width (mm)
10



Max. length per circuit (m)
5



IP rate
20/65



Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
117lm/W @Ra80
97.1lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
1483lm
 1231lm


2500K
 1550lm
 1273lm


2700K
 1671lm
 1328lm


3000K
 1685lm
 1398lm


3500K
 1718lm
 1426lm


4000K
 1685lm
 1398lm


5000K
 1752lm
 1496lm


6000K
 1752lm
 1496lm





Dimensions & available lengths



Illuminance Distribution




Feature / Warranty





◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.


IP rate




Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/7LEDs



Number LED/m
140



Voltage (v)
12V



Ra
80 / 90 / 95



Beam Angle(º)
120



Power (w/m)
10.5



FPC width (mm)
6



Max. length per circuit (m)
2.5



IP rate
20



Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
117lm/W @Ra80
97.1lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
1081lm
 897lm


2500K
 1130lm
 928lm


2700K
 1179lm
 969lm


3000K
 1253lm
 1020lm


3500K
 11253lm
 1040lm


4000K
 1320lm
 1095lm


5000K
 1278lm
 1091lm


6000K
 1278lm
 1091lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.




IP rate





Aluminum Profiles






    1616







        1708







            2308





Electrical & Output Data





Step length (mm/x LED)
25mm/3LEDs
50mm/5LEDs


Number LED/m
120
120


Voltage (v)
12V
24V


Ra
80 / 90 / 95
80 / 90 / 95


Beam Angle(º)
120
120


Power (w/m)
12.8
12.8


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
95lm/W @Ra80
78.9lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
1070m
 888lm


2500K
 1119lm
 918lm


2700K
 1167lm
 431lm


3000K
 547lm
 454lm


3500K
 1240lm
 1029lm


4000K
 1307lm
 1084lm


5000K
 1265lm
 1080lm


6000K
 1265lm
 1080lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.


IP rate



Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
83.4mm/6LEDs



Number LED/m
72



Voltage (v)
24V



Ra
80 / 90 / 95



Beam Angle(º)
120



Power (w/m)
13.8



FPC width (mm)
10



Max. length per circuit (m)
5



IP rate
20/65/66/67/68



Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
90lm/W @Ra80
74.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
1093lm
 907lm


2500K
 1143lm
 938lm


2700K
 1192lm
 979lm


3000K
 1242lm
 1031lm


3500K
 1267lm
 1051m


4000K
 1335lm
 1103lm


5000K
 1292lm
 1103lm


6000K
 1292lm
 1103lm





Dimensions & available lengths



Illuminance Distribution






Feature / Warranty







◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.




IP rate






Aluminum Profiles






    1616









         1708







            2308






Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/5LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80 / 90 / 95
80 / 90 / 95


Beam Angle(º)
120
120


Power (w/m)
5.76
11.52


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
90lm/W @Ra80
74.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
912lm
 757lm


2500K
 954lm
 783lm


2700K
 995lm
 818lm


3000K
 1037lm
 861lm


3500K
 1058lm
 878m


4000K
 1114lm
 924lm


5000K
 1078lm
 921lm


6000K
 1078lm
 921lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.




IP rate






Aluminum Profiles






    1616









        1708







            2308






Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/5LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80 / 90 / 95
80 / 90 / 95


Beam Angle(º)
120
120


Power (w/m)
5.76
5.76


FPC width (mm)
8
8


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
95lm/W @Ra80
78.9lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
482m
 400lm


2500K
 503lm
 413lm


2700K
 525lm
 431lm


3000K
 547lm
 454lm


3500K
 558lm
 463m


4000K
 588lm
 488lm


5000K
 569lm
 486lm


6000K
 569lm
 486lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







◆ 99.99% golden wire and copper support, super bright leds, stable and reliable.
◆ High lumen output, popular with very high cost-effective.
◆ Leds with one BIN system, consistent color, also Ra80/90/95 for choice.
◆ UL/CE/ROHS certification.
◆ Warranty: 3 years.



IP rate





Aluminum Profiles







     1616









        1708







            2308






Electrical & Output Data





Step length (mm/x LED)
100mm/3LEDs
166.6mm/5LEDs


Number LED/m
30
30


Voltage (v)
12V
24V


Ra
80 / 90 / 95
80 / 90 / 95


Beam Angle(º)
120
120


Power (w/m)
5.76
6.9


FPC width (mm)
8
8


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
90lm/W @Ra80
74.7lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
456lm
 379lm


2500K
 477lm
 392lm


2700K
 498lm
 409lm


3000K
 518lm
 430lm


3500K
 529lm
 439m


4000K
 557lm
 462lm


5000K
 539lm
 460lm


6000K
 539lm
 460lm






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆ We selected DC2.8-2.9V, 27-29LM, SMD2835 chips and adopted DC24V and 8 leds/group
solution to design 150LM/W Led Strips.
◆ Sometimes customer want high brightness but compliant heat dissipation problem,
150LM/W led strips could be a better choice.
◆ Adopt 1:2 OZ RA Copper PCB to reduce the voltage drop.
◆ We found that SMD2835 chips could get highest light efficiency when the drive current is 30ma.

IP rate



Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED)：50mm/24LEDs
Number LED/m：480
Voltage (v)：24V
Ra：80 / 90
Beam Angle(º)：120
Power (w/m)：40
FPC width (mm)：40
Max. length per circuit (m)：2.5
IP rate：20
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
150lm/W @Ra80
130lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 4920lm
 4264lm


2500K
 5160lm
 4472lm


2700K
 5400lm
 4680lm


3000K
 5580lm
 4836lm


3500K
 5700lm
 4940lm


4000K
 6000lm
 5200lm


5000K
 60000lm
 5200lm


6000K
 5820lm
 5044lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆ We selected DC2.8-2.9V, 27-29LM, SMD2835 chips and adopted DC24V and 8 leds/group
solution to design 150LM/W Led Strips.
◆ Sometimes customer want high brightness but compliant heat dissipation problem,
150LM/W led strips could be a better choice.
◆ Adopt 1:2 OZ RA Copper PCB to reduce the voltage drop.
◆ We found that SMD2835 chips could get highest light efficiency when the drive current is 30ma.

IP rate



Aluminum Profiles



Electrical & Output Data



Step length (mm/x LED)：25mm/8LEDs
Number LED/m：<320
Voltage (v)：24V
Ra：80 / 90
Beam Angle(º)：120
Power (w/m)：33.3
FPC width (mm) ：30
Max. length per circuit (m)：2.5
IP rate：20
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
150lm/W @Ra80
130lm/W @Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 4096lm
 3550lm


2500K
 4296lm
 3723lm


2700K
 4496lm
 3896lm


3000K
 4645lm
 4026lm


3500K
 4745lm
 4113lm


4000K
 4995lm
 4329lm


5000K
 4995lm
 4329lm


6000K
 4845lm
 4199lm





Dimensions & available lengths



Illuminance Distribution
