Products

Feature / Warranty



◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run




Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED)： 50mm/24LEDs
Number LED/m： 480
Voltage (v)： 24 V
Ra： 90
Beam Angle(º)： 120
Power (w/m)： 16
FPC width (mm)： 10
Max. length per circuit (m) ：6
IP rate： 20
Installation ：3M Tape / Mounting Clips / Aluminum Profiles



Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run




Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED) ：20mm/7LEDs
Number LED/m ：350
Voltage (v) ：24 V
Ra ：90
Beam Angle(º) ：120
Power (w/m) ：9.6
FPC width (mm)：4
Max. length per circuit (m) ：5
IP rate ：20
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
85.7lm/W @Ra90



LED color
Ra90



 = Popular Color
 = Niche Color


2300K
 723lm



2500K
 740lm



2700K
 789lm



3000K
 822lm



3500K
 838lm



4000K
 863lm



5000K
 863lm



6000K
 863lm






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run





Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED)：10mm/7LEDs
Number LED/m ：700
Voltage (v) ：24 V
Ra：90
Beam Angle(º) ：120
Power (w/m)：19.2
FPC width (mm) ：10
Max. length per circuit (m) ：5
IP rate ：20
Installation ：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
90.8lm/W @Ra90



LED color
Ra90



 = Popular Color
 = Niche Color


2300K
 1534lm



2500K
 1569lm



2700K
 1673lm



3000K
 1743lm



3500K
 1778lm



4000K
 1830lm



5000K
 1830lm



6000K
 1830lm






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run





Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED) ：12.5mm/8LEDs
Number LED/m：640
Voltage (v)： 24 V
Ra 90
Beam Angle(º) ：120
Power (w/m) ：19.2
FPC width (mm) ：10
Max. length per circuit (m)： 5
IP rate ：20
Installation ：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
102.5lm/W @Ra90



LED color
Ra90



 = Popular Color
 = Niche Color


2300K
 1732lm



2500K
 1771lm



2700K
 1889lm



3000K
 1968lm



3500K
 2007lm



4000K
 2066lm



5000K
 2066lm



6000K
 2066lm






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run




Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED)： 20mm/7LEDs
Number LED/m ：350
Voltage (v) ：24 V
Ra ：90
Beam Angle(º) ：120
Power (w/m) ：14.4
FPC width (mm) ：8
Max. length per circuit (m)： 6
IP rate：20/65/66/67/68
Installation ：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
88.3lm/W @Ra90



LED color
Ra90



 = Popular Color
 = Niche Color


2300K
 1118lm



2500K
 1144lm



2700K
 1220lm



3000K
 1271lm



3500K
 1296lm



4000K
 1344lm



5000K
 1344lm



6000K
 1344lm






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run






Aluminum Profiles






   1616







        1708







           2308






  Electrical & Output Data



Step length (mm/x LED)：50mm/7LEDs
Number LED/m：140
Voltage (v)：24 V
Ra：90
Beam Angle(º)：120
Power (w/m)：9.6
FPC width (mm)：8
Max. length per circuit (m)：7
IP rate：20/65/66/67/68
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
85.7lm/W @Ra90



LED color
Ra90



 = Popular Color
 = Niche Color


2300K
 723lm



2500K
 740lm



2700K
 789lm



3000K
 822lm



3500K
 838lm



4000K
 863lm



5000K
 863lm



6000K
 863lm






Dimensions & available lengths



Illuminance Distribution



Feature / Warranty



◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run






Aluminum Profiles


Electrical & Output Data



Step length (mm/x LED)：50mm/6LEDs
Number LED/m：120
Voltage (v)：24 V
Ra：90
Beam Angle(º)：120
Power (w/m)：9.6
FPC width (mm)：8
Max. length per circuit (m)：8
IP rate：20/65/66/67/68
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Light efficiency & Lumen Output





Luminaire efficacy (3000K)
73lm/W @Ra90



LED color
Ra90



 = Popular Color
 = Niche Color


2300K
 616lm



2500K
 630lm



2700K
 672lm



3000K
 700lm



3500K
 714lm



4000K
 735lm



5000K
 735lm



6000K
 735lm






Dimensions & available lengths



Illuminance Distribution
