◆ SMD2216 High density Series
◆ SMD2216 led chips are mini size and low cost, it could achieve high density line array.
◆ The spacing of leds is small, so it has excellent performance in luminous uniformity.
◆ And it could achieve low height linear lighting.
◆ Designed for 300 leds/m , 10mm per cuttable , cutting is more flexible.
◆ mini PCB series and CTA series.
IP Rate
◆ Because of the advantages of mini size, high brightness, high CRI and low cost,SMD2216 Led Chips could provide more flexible solution for application.
◆ Its good function of color consistence is suitable for Led strips application.
◆ According to its features, we have developed 4 kinds of SMD2216 led strip series: basic series, high density series,mini PCB series and CTA series.
IP Rate
◆ Because of the advantages of mini size, high brightness, high CRI and low cost,SMD2216 Led Chips could provide more flexible solution for application.
◆ Its good function of color consistence is suitable for Led strips application.
◆ According to its features, we have developed 4 kinds of SMD2216 led strip series: basic series, high density series,mini PCB series and CTA series.
IP Rate
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED)： 50mm/24LEDs
Number LED/m： 480
Voltage (v)： 24 V
Ra： 90
Beam Angle(º)： 120
Power (w/m)： 16
FPC width (mm)： 10
Max. length per circuit (m) ：6
IP rate： 20
Installation ：3M Tape / Mounting Clips / Aluminum Profiles
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED) ：20mm/7LEDs
Number LED/m ：350
Voltage (v) ：24 V
Ra ：90
Beam Angle(º) ：120
Power (w/m) ：9.6
FPC width (mm)：4
Max. length per circuit (m) ：5
IP rate ：20
Installation：3M Tape / Mounting Clips / Aluminum Profiles
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED)：10mm/7LEDs
Number LED/m ：700
Voltage (v) ：24 V
Ra：90
Beam Angle(º) ：120
Power (w/m)：19.2
FPC width (mm) ：10
Max. length per circuit (m) ：5
IP rate ：20
Installation ：3M Tape / Mounting Clips / Aluminum Profiles
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED) ：12.5mm/8LEDs
Number LED/m：640
Voltage (v)： 24 V
Ra 90
Beam Angle(º) ：120
Power (w/m) ：19.2
FPC width (mm) ：10
Max. length per circuit (m)： 5
IP rate ：20
Installation ：3M Tape / Mounting Clips / Aluminum Profiles
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED)： 20mm/7LEDs
Number LED/m ：350
Voltage (v) ：24 V
Ra ：90
Beam Angle(º) ：120
Power (w/m) ：14.4
FPC width (mm) ：8
Max. length per circuit (m)： 6
IP rate：20/65/66/67/68
Installation ：3M Tape / Mounting Clips / Aluminum Profiles
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
1616
1708
2308
Electrical & Output Data
Step length (mm/x LED)：50mm/7LEDs
Number LED/m：140
Voltage (v)：24 V
Ra：90
Beam Angle(º)：120
Power (w/m)：9.6
FPC width (mm)：8
Max. length per circuit (m)：7
IP rate：20/65/66/67/68
Installation：3M Tape / Mounting Clips / Aluminum Profiles
◆Compared with SMD2216, SMD2110 acts better for bending because of its strong frame.
◆ Its good function of strong frame is also suitable for extrusion led strips application.
◆ We adopt 7 leds/group and 8 leds/group design for high light efficiency.
◆ High quality doube-sided FPCB, Max 8m single run
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED)：50mm/6LEDs
Number LED/m：120
Voltage (v)：24 V
Ra：90
Beam Angle(º)：120
Power (w/m)：9.6
FPC width (mm)：8
Max. length per circuit (m)：8
IP rate：20/65/66/67/68
Installation：3M Tape / Mounting Clips / Aluminum Profiles
◆ Because of its advantages of mini size, high brightness and good heat dissipation, SMD3838 RGB LED chips could provide more flexible solution for application.
◆ Its good function of strong frame is also suitable for led strips application.
◆ According to its features, we have develoed 4 kinds of SMD3838 Led Strips: basic series, high density series, mini PCB series and long cascade series.
Aluminum Profiles
1616
1708
2308
Electrical & Output Data
Step length (mm/x LED) ：100mm/6LEDs
Number LED/m：60
Voltage (v) ：24 V
Ra ：NA
Beam Angle(º) ：120
Power (w/m) ：5.3
FPC width (mm) ：10
Max. length per circuit (m) ：15
IP rate ：20/67
Installation：3M Tape / Mounting Clips / Aluminum Profiles
◆ Because of its advantages of mini size, high brightness and good heat dissipation, SMD3838 RGB LED chips could provide more flexible solution for application.
◆ Its good function of strong frame is also suitable for led strips application.
◆ According to its features, we have develoed 4 kinds of SMD3838 Led Strips: basic series, high density series, mini PCB series and long cascade series.
Aluminum Profiles
Electrical & Output Data
Step length (mm/x LED)： 50mm/6LEDs
Number LED/m ：120
Voltage (v) ：24 V
Ra：NA
Beam Angle(º)：120
Power (w/m) ：8
FPC width (mm)：5
Max. length per circuit (m)：5
IP rate：20
Installation：3M Tape / Mounting Clips / Aluminum Profiles
2216-180-10mm-5m（High Density）
2216-120-8mm-5m（Basic Series）
2216-60-8mm-5m（Basic Series）
2110RGBW-480-10MM-5M（Multi-Color）
2110-350-4MM-5M（Mini PCB）
2110-700-10MM-5M（High Density）
2110-640-8MM-5M（High Density）
2110-350-8MM-5M（High Density）
2110-140-8MM-5M（Basic Series）
2110-120-8MM-5M（Basic Series）
3838RGB-60-10MM-15M（Long Cascade）
3838RGB-120-5MM-5M（Mini PCB）
