Feature / Warranty



◆ We use 0.5W super bright SMD5730 led chips, and the strips could reach 1932lm/m.
◆ It meets customer's need for high brightness.
◆ We adopt the design of double side FPC and 3OZ rolled copper technology to reduce the voltage drop and make sure the light consistence of led strips.


IP Rate




Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
120
60


Voltage (v)
12V
24V


Ra
90 / 95
90 / 95


Beam Angle(º)
120
120


Power (w/m)
7
7


FPC width (mm)
8
8


Max. length per circuit (m)
2.5
2.5


IP rate
20
20


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
92lm/W @Ra80


LED color
Ra80


 = Popular Color
 = Special Color


2700K
 1590lm


3000K
 1656lm


4000K
 1788lm


6000K
 1788lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



◆ We use 0.5W super bright SMD5730 led chips, and the strips could reach 1932lm/m.
◆ It meets customer's need for high brightness.
◆ We adopt the design of double side FPC and 3OZ rolled copper technology to reduce the voltage drop and make sure the light consistence of led strips.


IP Rate



Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
41.7mm/3LEDs
83.3mm/6LEDs


Number LED/m
72
72


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
21
21


FPC width (mm)
11
11


Max. length per circuit (m)
2.5
2.5


IP rate
20
20


Installation
3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output





Luminaire efficacy (3000K)
92lm/W @Ra80


LED color
Ra80


 = Popular Color
 = Special Color


2700K
 1855lm


3000K
 1932lm


4000K
 2087lm


6000K
 2087lm





Dimensions & available lengths



Illuminance Distribution

Feature / Warranty





The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space


IP rate





Aluminum Profiles





   1616







       1708







             2308






Electrical & Output Data



Step length (mm/x LED)：100mm/3LEDs
Number LED/m：30
Voltage (v)：12 V
Ra：NA
Beam Angle(º)：120
Power (w/m)：7.2
FPC width (mm)：10
Max. length per circuit (m)：5
IP rate：20/65/66/67/68
Installation：3M Tape / Mounting Clips / Aluminum Profiles





Dimensions & available lengths



Illuminance Distribution






Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space

IP rate


Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
14.4
19.2


FPC width (mm)
12
12


Max. length per circuit (m)
5
5


IP rate
20/65
20/65


Installation
3M Tape / Mounting Clips / Aluminum Profiles






Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate


Aluminum Profiles




Electrical & Output Data



Step length (mm/x LED)：100mm/18LEDs
Number LED/m：180
Voltage (v)：24 V
Ra：80
Beam Angle(º)：120
Power (w/m)：19.2
FPC width (mm)：12
Max. length per circuit (m)：5
IP rate：20/65
Installation：3M Tape / Mounting Clips / Aluminum Profiles



Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate



Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
17.2
17.2


FPC width (mm)
12
12


Max. length per circuit (m)
5
5


IP rate
20/65
20/65


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate


Aluminum Profiles


Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80
80


Beam Angle(º)
120
120


Power (w/m)
17.2
17.2


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65
20/65


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty



The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space


IP rate


Aluminum Profiles



Electrical & Output Data



Step length (mm/x LED)：62.5mm/6LEDs
Number LED/m：96
Voltage (v)：24 V
Ra：NA
Beam Angle(º)：120
Power (w/m)：18.43
FPC width (mm)：10
Max. length per circuit (m)：5
IP rate：20/65
Installation：3M Tape / Mounting Clips / Aluminum Profiles





Light efficiency & Lumen Output



Illuminance Distribution

Feature / Warranty





The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space


IP rate





Aluminum Profiles





   1616







       1708







             2308





Electrical & Output Data







Step length (mm/x LED)
100mm/6LEDs
166.6mm/10LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
11.52
13.8


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty





The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space


IP rate





Aluminum Profiles





   1616







       1708







             2308





Electrical & Output Data





Step length (mm/x LED)
50mm/3LEDs
100mm/6LEDs


Number LED/m
60
60


Voltage (v)
12V
24V


Ra
NA
NA


Beam Angle(º)
120
120


Power (w/m)
11.52
11.52


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles







Dimensions & available lengths



Illuminance Distribution

Feature / Warranty







The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light,
free to change the atmosphere of space




IP rate





Aluminum Profiles





   1616







       1708







           2308




Electrical & Output Data






Step length (mm/x LED)
25mm/3LEDs
166.6mm/5LEDs


Number LED/m
30
30


Voltage (v)
12V
24V


Ra
NA
NA


Beam Angle(º)
120
120


Power (w/m)
5.76
6.9


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Profiles











Dimensions & available lengths






Illuminance Distribution

Feature / Warranty







The SMD5050 strips could provide high quality white color and RGB/RGBW/RGBCTA full changing light, free to change the atmosphere of space



IP rate




Aluminum Profiles





     1616







         1708







            230






Electrical & Output Data





Step length (mm/x LED)
100mm / 3LEDs
166.6mm / 6LEDs


Number LED/m
30
60


Voltage (v)
12V
24V


Ra
80 / 90
80 / 90


Beam Angle(º)
120
120


Power (w/m)
11.52
11.52


FPC width (mm)
10
10


Max. length per circuit (m)
5
5


IP rate
20/65/66/67/68
20/65/66/67/68


Installation
3M Tape / Mounting Clips / Aluminum Pro?les





Light efficiency & Lumen Output





Luminaireeficacy (3000K)
95lm/W@Ra80
79.8lm/W@Ra90


LED color
Ra80
Ra90


 = Popular Color
 = Niche Color


2300K
 947lm
 809lm


2500K
 985lm
 827lm


2700K
 1040lm
 905lm


3000K
 1094lm
 919lm


3500K
 1094lm
 938lm


4000K
 1094lm
 992lm


5000K
 1094lm
 967lm


6000K
 1058lm
 967lm





Dimensions & available lengths



Illuminance Distribution
