Product Description
Product Name: 100w modular LED flood lights
Beam angle: 30°, 60°, 90°, 80°*150°, 90°*120°, using Philips super bright 3030 smd(P or Q bin only)



Power:
100W


Working voltage:
AC100-277V, 50/60Hz


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-5500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
130-140LM/W


CONFIGURATIONS


LED chip:
Lumileds 3030 smd


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%  RH


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
TUV, SAA, C-TICK, CE, RoHS




Dimension of 100w modular led flood lights:


Applications:

Widely used for tunnel, street, billboard, outdoor tennis court, shop, factory, warehouse, workshop, etc.



Product Description
Product Name: 150w modular LED flood lights
Beam angle: 30°, 60°, 90°, 80°*150°, 90°*120°, using Philips super bright 3030 smd(P or Q bin only)




Power:
150W


Working voltage:
AC100-277V, 50/60Hz


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-5500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
130-140LM/W


CONFIGURATIONS


LED chip:
Lumileds 3030 smd


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%  RH


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
TUV, SAA, C-TICK, CE, RoHS




Dimension of 150w modular led flood lights:


Applications:

Widely used for tunnel, street, billboard, outdoor tennis court, shop, factory, warehouse, workshop, etc.



Product Description
Product Name: 200w modular LED floodlights
Beam angle: 30°, 60°, 90°, 80°*150°, 90°*120°, using Philips super bright 3030 smd(P or Q bin only)




Power:
200W


Working voltage:
AC100-277V, 50/60Hz


PF:
> 0.97


TECHNICAL CHARACTERISTICS


Color:
Warm White
Natural White
Cool White


Color Temperature:
2700-3200K
4000-5500K
6000-6500K


CRI:
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra
>70Ra, can be over 80Ra


Lumens:
130-140LM/W


CONFIGURATIONS


LED chip:
Lumileds 3030 smd


LED driver:
Mean Well, SOSEN


Heat sinks:
Aluminum


Body color:
Black


OTHERS


Operating Temperature:
-35℃  to  50℃


Operating Humidity:
10%-90%  RH


Storage Temperature:
-35℃  to  60℃


Warranty:
5 Years


Certificates:
TUV, SAA, C-TICK, CE, RoHS




Dimension of 200w modular led floodlights:


Applications:

Widely used for tunnel, street, billboard, outdoor tennis court, shop, factory, warehouse, workshop, etc.


Product Description
Product Name: 240w modular LED flood lights

Beam angle: 30°, 60°, 90°, 80°*150°, 90°*120°, using Philips super bright 3030 smd(P or Q bin only)





Power:


240W




Working voltage:


AC100-277V, 50/60Hz




PF:


> 0.97




TECHNICAL CHARACTERISTICS




Color:


Warm White


Natural White


Cool White




Color Temperature:


2700-3200K


4000-5500K


6000-6500K




CRI:


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra


>70Ra, can be over 80Ra




Lumens:

130-140LM/W



CONFIGURATIONS




LED chip:


Lumileds 3030 smd




LED driver:


Mean Well, SOSEN




Heat sinks:


Aluminum




Body color:


Black




OTHERS




Operating Temperature:


-35℃  to  50℃




Operating Humidity:


10%-90%  RH




Storage Temperature:


-35℃  to  60℃




Warranty:


5 Years




Certificates:


TUV, SAA, C-TICK, CE, RoHS






Dimension of 240w modular led flood lights:



Applications:

Widely used for tunnel, street, billboard, outdoor tennis court, shop, factory, warehouse, workshop, etc.
